Lathe Chuck 3 Jaws Self Centering
US$ 15 - 80
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
STC
Model Number:
R10
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CNC Lathe Chuck 4 Jaws Self CenteringUS$ 15 - 100MOQ: 1 Piece -
Pull Stud DIN69872-1988NegotiableMOQ: 100 Pieces
-
Pull Stud Retention Knob ANSI/ASME B5.50-1985NegotiableMOQ: 100 Pieces
-
Pull Stud Retention Knob ISO/DIS7388/S-1984ANegotiableMOQ: 100 Pieces
-
Pull Stud Retention Knob JIS B6339-1986NegotiableMOQ: 100 Pieces
Place of Origin
Jiangsu, China
Brand Name
STC
Model Number
R10
Power
Manual
Number of Jaws
3
3 jaws Self centring Lathe chuck
Direct mounting self centering lathe chuck
Three-jaw Self-centering chuck is subdivided into three types,K11,K11A,K11C.
Type K11A provides,ISO3442 standard clutches,and Type K11C provides traditional separate clutches.
Soft clutches are to be provided on request,higher centring accuracy can be achieved after being rubbed on the machine,so as to satisfy the need for holding.
| Model Size D |
D1 | D2 | D3 | H | H1 | H2 | h | Z-d |
| K1180 | 55 | 66 | 16 | 66 | 50 | - | 3.5 | 3-M6 |
| K11100 | 72 | 84 | 22 | 74.5 | 55 | - | 3.5 | 3-M8 |
| K11125 | 95 | 108 | 30 | 84 | 58 | - | 4 | 3-M8 |
| K11130 | 100 | 115 | 30 | 86 | 60 | - | 3.5 | 3-M8 |
| K11160 | 130 | 142 | 40 | 95 | 65 | - | 5 | 3-M8 |
| K11160A | 142 | 40 | 109 | 65 | 71 | 5 | 3-M8 | |
| K11165 | 145 | 40 | 96.5 | 66.5 | - | 4.5 | 3-M8 | |
| K11165A | 145 | 40 | 110.5 | 66.5 | 72.5 | 4.5 | 3-M8 | |
| K11190 | 155 | 172 | 55 | 109 | 75 | - | 5 | 3-M10 |
| K11190A | 172 | 55 | 122 | 75 | 80 | 5 | 3-M10 | |
| K11200 | 165 | 180 | 65 | 109 | 75 | - | 5 | 3-M10 |
| K11200A | 180 | 65 | 122 | 75 | 80 | 5 | 3-M10 | |
| K11200C | 180 | 65 | 122 | 75 | 78 | 5 | 3-M10 | |
| K11240 | 195 | 215 | 70 | 120 | 80 | - | 8 | 3-M12 |
| K11240A | 215 | 70 | 136 | 80 | 86 | 8 | 3-M12 | |
| K11240C | 215 | 70 | 130 | 80 | 84 | 8 | 3-M12 | |
| K11250 | 206 | 226 | 80 | 120 | 80 | - | 5 | 3-M12 |
| K11250A | 226 | 80 | 136 | 80 | 86 | 5 | 3-M12 | |
| K11250C | 226 | 80 | 130 | 80 | 84 | 5 | 3-M12 |
Model |
D1 | D2 | D3 | H | H1 | H2 | h | z-d |
| K11315 | 260 | 285 | 100 | 142.5 | 90 | - | 6 | 3-M16 |
| K11315A | 285 | 100 | 155.5 | 90 | 96.5 | 6 | 3-M16 | |
| K11315C | 285 | 100 | 155.5 | 90 | 96.5 | 6 | 3-M16 | |
| K11320 | 270 | 290 | 100 | 142.5 | 90 | - | 6 | 3-M16 |
| K11320A | 290 | 100 | 155.5 | 90 | 96.5 | 6 | 3-M16 | |
| K11320C | 290 | 100 | 155.5 | 90 | 96.5 | 6 | 3-M16 | |
| K11325 | 272 | 296 | 100 | 142.5 | 90 | - | 6 | 3-M16 |
| K11325A | 296 | 100 | 155.5 | 90 | 96.5 | 6 | 3-M16 | |
| K11325C | 296 | 100 | 155.5 | 90 | 96.5 | 6 | 3-M16 | |
| K11380 | 325 | 350 | 130 | 155.5 | 100 | - | 6 | 3-M16 |
| K11380A | 350 | 130 | 171.5 | 100 | 110.5 | 6 | 3-M16 | |
| K11380C | 350 | 130 | 164.5 | 100 | 105.5 | 6 | 3-M16 | |
| K11400 | 340 | 368 | 130 | 155.5 | 100 | - | 6 | 3-M16 |
| K11400A | 368 | 130 | 171.5 | 100 | 110.5 | 6 | 3-M16 | |
| K11400C | 368 | 130 | 164.5 | 100 | 105.5 | 6 | 3-M16 | |
| K11500 | 440 | 465 | 200 | 181 | 115 | - | 6 | 6-M16 |
| K11500A | 465 | 200 | 203 | 115 | 123 | 6 | 6-M16 | |
| K11630 | 560 | 595 | 260 | 194 | 130 | - | 7 | 6-M16 |
| K11630A | 595 | 260 | 218 | 130 | 138 | 7 | 6-M16 | |
| K11800A | 710 | 760 | 385 | 242 | 149 | 159 | 8 | 6-M20 |
