Pull Stud Retention Knob JIS B6339-1986
Negotiable
/ Piece
100 Pieces(Min. Order)
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | STC | |
| Model Number | P94 |
Product Description
Retention knob,also called pull stud.
Material: 45Mn.
Types:
JIS B6339-1986
Model | D | D1 | D2 | M | L | L1 | L2 | H | H1 |
30P | 12.5 | 8 | 12 | M12 | 43 | 23.4 | 18.4 | 5 | 3 |
35P | 11 | 15 | 44 | 24 | 19 | ||||
40P | 17 | 14 | 19 | M16 | 54 | 29 | 23 | 7 | |
45P | 21 | 17 | 23 | M20 | 60 | 30 | 4 | ||
50P | 25 | 21 | 28 | M24 | 74 | 34 | 25 | 5 | |
55P | 31 | 27 | 36 | M30 | 98 | 48 | 36 | 11 | 7 |
