Commercial laundry self-service washing machine

1.Automatic and programmable controlling system with touching screen.

2.Adopt the most advanced international suspension structure to absorb vibration.

3.Drum is made of stainless steel, corrosion resistance and durable.

4.All closed, loading and unloading in front, water inlet and outlet at the back of the machine, so there is no environmental pollution.

5.Using high precision converter motor and famous brand frequency inverters to make the machine running smoothly and reliable.

Type

XTQ-15H

XTQ-20H

XTQ-30H

XTQ-50H

XTQ-70H

XTQ-100H

rated capacity

Min

10kg

15kg

20kg

35kg

50kg

70kg

Max

15kg

20kg

30kg

50kg

70kg

100kg

Drum

Diameter

636mm

700mm

900mm

1080mm

1080mm

1200mm

Diameter deepness

470mm

500mm

500mm

575mm

730mm

856mm

Overall Dimension

Height

1300mm

1400mm

1635mm

1800mm

1800mm

2030mm

Length

1240mm

1260mm

1460mm

1610mm

1760mm

1990mm

Width

1000mm

1050mm

1400mm

1650mm

1550mm

1690mm

Motor

1.5kw

2.2kw

3kw

4kw

5.5kw

7.5kw

Filling with water

Hot water pipe

3/4"

3/4"

3/2"

3/2"

3/2"

3/2"

Cold water pipe

3/4"

3/4"

3/2"

3/2"

3/2"

3/2"

Steam pipe

3/4"

3/4"

1"

1"

1"

1"

Power supply

Standard:380+N-3PH-50HZ
