Home > Products > Axial Fan with External Rotor Motor > 600mm ac Ventilation Fan Motor for Cooling
600mm ac Ventilation Fan Motor for Cooling
- ningbo/shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Electric Current Type | AC | Mounting | Other, axial fan | |
| Blade Material | Cast Iron | Place of Origin | Zhejiang, China | |
| Brand Name | FENGDA | Model Number | YWF | |
| Voltage | 220V or 380V | Power | 750W | |
| Air Volume | 10850 m3/h | Speed | 1350 RPM | |
| Certification | CCC, CE, CSA, GS, ROHS, UL | After-sales Service Provided | Overseas third-party support available |
Product Description
600mm ac ventilation fan motor for cooling
1, Fan diameter : 200mm to 900mm.
2, The voltage :120V/60Hz ,220V/50Hz,380V/50Hz or according to customer's requirements.
3,The using life is over 30000 hours.
4,The using ambient temperature is from -30°c to 60°c
5,The motors are 100% pure copper
6, Airflow Direction: Suction or Blowing.
Model | Voltage V | Frequency Hz | Current A | Input Power W | Speed RPM | Max Air Flow m3/h | Capacitor uF | Noise dB(A) | Curve
|
YWF4D600 | 380 | 50 | 1.61 | 750 | 1350 | 10850 | / | 78 | 1 |
YWF4E600 | 220 | 50 | 3.3 | 710 | 1350 | 10850 | 16 | 78 | 1 |
YWF6D600 | 380 | 50 | 1.2 | 380 | 900 | 8100 | / | 72 | 2 |
YWF6E600 | 220 | 50 | 2.5 | 390 | 900 | 8100 | 12 | 72 | 2 |
FENGDA was establish in 1990,covering an area of 17,000 square meters,more than 200 employes.We professionally manufacture various fans and motors,which widely used in Ventilation,air condittion,air condition,cooling and heating industry.
We have gotten CE,UL,CCC certificates and ISO9001 Quality Management System Certification.nd our products are exporting to Europe and America,Middle East,Russia etc.
One piece in one single carton
1,We could provide the OEM service.
2,We also could repair the goods for you after the warranty period.
3.Warranty period could be 2 years.
1. Q: Do you provide warranty for the goods?
A: Yes, we provide warranty for all the goods from us.
2. Q: Could FENGDA provide technology support?
A: We're in this field many years. If there's any problem, please contact with us,we'll provide suggestion from our engineer to help you solve problem.
3. Q: Does FENGDA keep goods in stock or only trading?
A: We have large warehouse for goods. Keep lots of goods in warehouse, so could promise fast delivery.
4. Q: Could you fill the invoice for customs as our requirement?
A: Yes, if there's any requirement for it, please tell us. We'll do it.
1, Water Cooler 2.Air Cooler 3.Heater 4.Heat Pump 5.Evaporator 6.Dehumidifier
