VB 3200 HVAC Control Valve

VB 3200 HVAC Control Valve thumbnail-1
VB 3200 HVAC Control Valve thumbnail-2
VB 3200 HVAC Control Valve thumbnail-3
VB 3200 HVAC Control Valve thumbnail-4
VB 3200 HVAC Control Valve photo-1
VB 3200 HVAC Control Valve photo-2
VB 3200 HVAC Control Valve photo-3
VB 3200 HVAC Control Valve photo-4
US$ 15 - 300 MOQ: 10 Units
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Check
Pressure:
Medium Pressure
Contact Supplier Request Quote Chat Now
Xiamen Ronglin Electronics Technology And Development Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Standard or Nonstandard Standard
Structure Check
Pressure Medium Pressure
Power Other, Actuator
Material Brass
Temperature of Media Normal Temperature
Media Water
Port Size DN 15 ~ DN 65
Place of Origin Fujian, China
Model Number VB 3200
Brand Name Roleen

Specifications

asted brass, and applicable for hot water, cold water and low pressure steam system.

VB 3200 Control Valve



VB3200 Series Valve is made of casted brass, and applicable for hot water, cold water and low pressure steam system.


Core: 1Cr18Ni9TiBrass
Valve Body: Brass
Stem: AISI302 Stainless Steel
Paddle:  4 EPDM V-rings and O-rings, lubricated
Nominal Pressure: 1.6 Mpa
Media: Water
Liquid temp: -10~95℃
Leakage:

Less than 0.1% of KV value

Model#

DN

mm

Config.

KV

Max.Diff.Pressure

Mpa

Stroke

A(B)

C

VB3200A/B/C-215JC/HC

15

2 way

4.0

2.5

0.6

15

VB3200A/B/C-220 JC/HC

20

2 way

6.3

3.7

0.6

15

VB3200A/B/C-225 JC/HC

25

2 way

8

5.3

0.6

20

VB3200A/B/C-232 JC/HC

32

2 way

16

9.5

0.6

20

VB3200A/B/C-240 JC/HC

40

2 way

25

11

0.6

20

VB3200A/B/C-250 JC/HC

50

2 way

40

16

0.6

20

VB3200A/B/C-315 JC/HC

15

3 way

4.0

2.5

0.6

15

VB3200A/B/C-320 JC/HC

20

3 way

6.3

3.7

0.6

15

VB3200A/B/C-325 JC/HC

25

3 way

8

5.3

0.6

20

VB3200A/B/C-332 JC/HC

32

3 way

16

9.5

0.6

20

VB3200A/B/C-340 JC/HC

40

3 way

25

11

0.6

20

VB3200A/B/C-350 JC/HC

50

3 way

40

16

0.6

20

VB3200A/B/C-265 JC/HC

65

2 way

63

-

0.25

20

VB3200A/B/C-280 JC/HC

80

2 way

78

-

0.20

20

VB3200A/B-365 JC/HC

65

3 way

63

-

0.25

20

VB3200A/B-380 JC/HC

80

3 way

78

-

0.20

20

Remarks: A Normal Brass Body                   JC   J Coupling

         B Thicker Brass Body                   JH   H Coupling

         C Forged Brass Body
