VB 7200 AHU Control Valve

VB 7200 AHU Control Valve thumbnail-1
VB 7200 AHU Control Valve photo-1
US$ 50 - 600 MOQ: 10 Units
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Check
Pressure:
Medium Pressure
Contact Supplier Request Quote Chat Now
Xiamen Ronglin Electronics Technology And Development Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Standard or Nonstandard Standard
Structure Check
Pressure Medium Pressure
Power Other, Actuator
Material Brass
Temperature of Media Normal Temperature
Media Water
Port Size DN 32 ~ DN 150
Place of Origin Fujian, China
Model Number VB 7200
Brand Name Roleen

Specifications

casted steel, and applicable for hot water, cold water and low pressure steam system.

VB 7200 Control Valve



VB7200 Series Valve is made of casted steel, and applicable for hot water, cold water and low pressure steam system.


Part No &Specification


Core: AISI302 Stainless Steel
Valve Body: HT250 CastedIron
Stem: AISI302 Stainless Steel
Paddle:  EPDM O-rings
Nominal Pressure: 1.6 Mpa
Media: Water
Liquid temp: -10~95℃
Leakage:

Less than 0.1% of KV value

Part No &Specification



Model#

DN

mm

Config.

KV

Max. Diff.Pressure (Mpa)

Stroke

mm

H

J

X

VB7200-232H/J/X

32

2 way

25

0.6

0.6

0.6

20

VB7200-240 H/J/X

40

2 way

32

0.6

0.6

0.6

20

VB7200-250 H/J/X

50

2 way

50

0.6

0.6

0.6

20

VB7200-265 H/J/X

65

2 way

75

0.6

0.6

0.6

20

VB7200-280 H/J/X

80

2 way

100

0.6

0.6

0.6

20

VB7200-2100 H/J/X

100

2 way

125

0.6

0.6

0.6

38

VB7200-2125 H/J/X

125

2 way

200

0.5

0.5

0.5

38

VB7200-2150 H/J/X

150

2 way

285

0.5

0.5

0.5

38

VB7200-2200 H/J/X

200

2 way

400

0.4

0.4

0.4

38

VB7200-332 H/J/X

32

3 way

25

0.6

0.6

0.6

20

VB7200-340 H/J/X E

40

3 way

32

0.6

0.6

0.6

20

VB7200-350 H/J/X E

50

3 way

50

0.5

0.5

0.5

20

VB7200-365 H/J/X E

65

3 way

75

0.5

0.5

0.5

20

VB7200-380 H/J/X

80

3 way

100

0.5

0.5

0.5

20

VB7200-3100 H/J/X

100

3 way

125

0.3

0.3

0.5

38

VB7200-3125 H/J/X

125

3 way

200

0.2

0.2

0.5

38

VB7200-3150 H/J/X

150

3 way

285

0.15

0.15

0.3

38

VB7200-3150 H/J/X

200

3 way

400

0.1

0.1

0.2

38

Remarks: A Normal Brass Body                   J    J Coupling

         B Thicker Brass Body                   H    H Coupling

         C Forged Brass Body                    X    X Coupling
