TD/TA 02/04 Series On/off or Modulating Damper Actuator

Name: TD/TA 02/04 Series On/off or Modulating Damper Actuator
Brand: Roleen
SKU: 133087463
Availability: InStock

TD/TA 02/04 Series On/off or Modulating Damper Actuator thumbnail-1

TD/TA 02/04 Series On/off or Modulating Damper Actuator photo-1

US$ 20 - 60 MOQ: 20 Units

Key Specifications

Get Latest Price

Place of Origin:

Fujian, China

Brand Name:

Roleen

Model Number:

TD/TA 02/04

Contact Supplier Request Quote Chat Now

Xiamen Ronglin Electronics Technology And Development Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xiamen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Fujian, China

Brand Name Roleen

Model Number TD/TA 02/04

Type HVAC Systems

Specifications

installed to the Damper, Ventilation window, VAV and other equipments directly to adjust the switch, floating and proportion.

TD/TA 02/04 Series On/off or Modulating Damper Actuator

TD/TA 02/04 Series Damper Actuator is specially designed for the damper control of HVAC system. The product supplies 2-4 Nm torque could be installed to the Damper, Ventilation window, VAV and other equipments directly to adjust the switch, floating and proportion.

Specification & PartNo

Model#	TDS02/04,TDF02/04,TDS02/04,TA02/04
Tolerance	± 10%
Output Torque	2 N.m., 4 N.m.
Running Time	80~90 Sec
Running Consumption	4VA
Standstill Consumption	1~4VA
Output Angle	90. (Max 95.)
Control Signal	TDS 2 point on/off controls
	TDF 3 point and 2 point on/off control
	TA DC(0)2~10 V
Shaft Diameter Range	φ6~16 mm or φ 5~11mm
Overload Protection	Automatic
IP Class	IP54
Ambient Temp. Range	-10~55℃ 0~90%rh
Max. Noise	40dB(A)
N.W.	0.6~0.8 kg

Model#	Torque -N.m.	Power Supply	Running Consumption -VA	Standstill Consumption -VA	Running time -Sec	OutputAngle Range
TDS02-230	2	AC230V	12	12	80~90	0~95.
TDF02-24	2	AC/DC24V	4	4	80~90	0~95.
TDS02-120	2	AC120V	12	12	80~90	0~95.
TDS04-230	4	AC230V	12	12	80~90	0~95.
TDF04-24	4	AC/DC24V	4	4	80~90	0~95.
TDS04-120	4	AC120V	12	12	80~90	0~95.
TA02-24	2	AC/DC24V	4	4	80~90	0~95.
TA04-24	4	AC/DC24V	4	4	80~90	0~95.
