RL 2088 Two-way/Three-way 3-wire On-off/Modulating Motorized Ball Valve

Name: RL 2088 Two-way/Three-way 3-wire On-off/Modulating Motorized Ball Valve
Brand: Roleen
SKU: 133087345
Availability: InStock

RL 2088 Two-way/Three-way 3-wire On-off/Modulating Motorized Ball Valve thumbnail-1

RL 2088 Two-way/Three-way 3-wire On-off/Modulating Motorized Ball Valve photo-1

US$ 15 - 25 MOQ: 50 Units

Key Specifications

Get Latest Price

Standard or Nonstandard:

Standard

Structure:

Ball

Pressure:

Medium Pressure

Contact Supplier Request Quote Chat Now

Xiamen Ronglin Electronics Technology And Development Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xiamen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Standard or Nonstandard Standard

Structure Ball

Pressure Medium Pressure

Power Other, AC hysteresis Synchronous

Material Brass

Temperature of Media Normal Temperature

Media Water

Port Size DN 15 DN 20 DN 25

Place of Origin Fujian, China

Model Number RL2028

Brand Name Roleen

Specifications

Actuator could be installed after the valve body is fixed.

RL 2088Two-way/Three-way 3-wireOn-off/Modulating Motorized Ball Valve

RL 2088 Series Motorized Ball Valves are used to control water flow in air-conditioning water system. It is constructed of actuator and valve body mainly. Actuator takes use of synchronous motor and limit switch, which works steadily and is able to cut power off when the valve opens or closes completely

Part No &Specification

Power Consumption:	2 W
Motor:	Synchronous Motor
Actuator:	ABS Plastic
Ball	Chrome plated brass
Valve Body:	Forging Brass
Stem:	Brass
Paddle:	2 EPDM O-rings, lubricated

Model#	Screw & Size	Config.	KV	Pressure Mpa	Medium	Media Temp.	Ambient Temp.	Running Time	Power Supply
RL2088-215	G1/2(15mm)	2-way, Normally Close	4.0	1.6	Chilled Water or Hot Water	5~95℃	0~65℃	40~50 Sec	24/110/220 Vac, + 10%, 50/60Hz
RL2088-220	G3/4(20mm)	2-way, Normally Close	4.0	1.6
RL2088-225	G1 (25mm)	2-way, Normally Close	10.0	1.6
RL2088-315	G1/2(15mm)	3-way, Diverting	4.0	1.6
RL2088-320	G3/4(20mm)	3-way, Diverting	4.0	1.6
RL2088-325	G1 (25mm)	3-way, Diverting	10.0	1.6
