WB 7000 2 way/3 way RF Wireless Motorized Ball Valve
- Xiamen
- T/T Credit Card
You May Like
-
RL 8068 Series Two-way / Three-way 2-wire On/off Motorized Valve
-
RL 8068-5 Two-way/Three-way 5-wire On/off Motorized Valve
-
RL 8068C-5 Two-way/Three-way 5-wire On/off Coupling Motorized Valve
-
RL 8058 Two-way/Three-way 2-wire On/off Motorized Valve
-
RL 6088 Two-way/Three-way 2-wire On/off Motorized Valve
-
RL 2088 Two-way/Three-way 3-wire On-off/Modulating Motorized Ball Valve
Product Details
| Standard or Nonstandard | Standard | Structure | Ball | |
| Pressure | Medium Pressure | Power | Other, AC hysteresis Synchronous | |
| Material | Brass | Temperature of Media | Normal Temperature | |
| Media | Water | Port Size | DN 15 DN 20 DN 25 | |
| Model Number | WB7000 | Brand Name | Roleen |
Product Description
Specifications
RF Wireless Balll ValveWB 7000 Wireless Motorized Ball Valve
WB 7000 Wireless Motorized Ball Valves are used to control water flow in air-conditioning water system. It is constructed of actuator and valve body mainly. Actuator takes use of synchronous motor and RF Semi-duplex Module. The complete motorized valve works with a RF room thermostat, which save the wiring between them and make the installation easier in whole system.
Part No &Specification
| Power Consumption: | 2 W |
| Motor: | Synchronous Motor |
| Actuator: | ABS Plastic |
| Ball | Chrome plated brass |
| Valve Body: | Forging Brass, Stainless Steal |
| Stem: | Brass |
| Paddle: | 2 EPDM O-rings, lubricated |
Model# | Screw & Size | Config. | KV | Pressure Mpa | Medium | Media Temp. | Ambient Temp. | Running Time | Power Supply |
WB7000-215 | G1/2(15mm) | 2-way, Normally Close | 4.0 | 1.0 | Chilled Water or Hot Water | 2~95℃ | 0~65℃ | 5~15 Sec | 24/110/220 Vac, + 10%, 50/60Hz |
WB7000-220 | G3/4(20mm) | 2-way, Normally Close | 4.0 | 1.0 | |||||
WB7000-225 | G1 (25mm) | 2-way, Normally Close | 10.0 | 1.0 | |||||
WB7000-315 | G1/2(15mm) | 3-way, Diverting | 4.0 | 1.0 | |||||
WB7000-320 | G3/4(20mm) | 3-way, Diverting | 4.0 | 1.0 | |||||
WB7000-325 | G1 (25mm) | 3-way, Diverting | 10.0 | 1.0 |
