Help Center0.1um Nylon 66 Pleated Filter Cartridge for Wine/beer/drinking Water
Related Products
-
Nylon Micropore Pleated Oil Filter Cartridge for Wine Used With Great PriceUS$ 22 - 45MOQ: 10 Pieces -
Sterilizing Grade Nylon Filter Cartridge for WFI Water in Great PriceUS$ 18 - 40MOQ: 10 Pieces
-
PP/PTFE/PES 10/20/30 Inch 0.1 Micron Pleated Filter Cartridge For Water TreatmentUS$ 2 - 5MOQ: 10 Pieces
-
Wuhu Millipore Membrane Filter/micron Filter/pleated Filter Cartridge for Beverage and ChemicalUS$ 2 - 4MOQ: 20 Pieces
-
1 Micron 10 Inch PP Pleated Filter Element for Mineral Water FiltrationUS$ 1 - 2MOQ: 20 Pieces
Specifications:
Filter membrane |
Nylon6 or nylon6 micropore membrane |
Diversion layer |
PP no-woven or screen fabric |
Housing |
PP no-woven |
Inner support |
PP or PP with stainless lining |
OD |
68mm 69mm |
ID |
32mm |
Length |
5~40" |
Seal ring |
Silicon,EPDM,Nitrile,fluorous,fluorous with PTEF |
Precision |
0.10,0.20,0.45,0.65,1.00,3.00µm |
Effective area |
Area≥0.65m² |
PH value |
6~13 |
normal working temperature |
≤60℃ |
Max. working temperature |
85℃,P≤0.10Mpa |
Max.differential pressure |
25℃,forward direction 0.42Mpa,reverse direction 0.21MPa |
Sterilization |
121±2℃ steam for 30min/once or sterile cabinet for 30min/once |
Endotoxin |
<0.25EU/ml |
Extractive |
<0.03g/10"cartridge |
Electronic grade |
Hundred thousand grade purify workshop,18M ultra purify water backwash, which meets with the electronic requirements. |
Pharmacy grade |
Hundred thousand grade purify workshop, purify water backwash, which meets with the GMP standards. |
Food grade |
Hundred thousand grade purify workshop,purify water backwash, which meets withthe FDA safety regulations . |
Water treatment grade |
Purify workshop, sterile air purge. |
2. Mainly characteristics
Nylon membrane( made on steel belt)0.3 times faster than enhanced nylon membrane.
Widely filter precision and selectivity, available for various situations
Adopt fluid dynamics design, high effective
Electrostatic adsorption and micropore filtration.
Ultrasonic welding, without adhesives.
Evenly pore, great mechanical strength
Great ability of removing particles
Oil resistance and organic solvent resistance.
Absolutely precision
Long service life
Q1. Can I have a sample order for filter cartridge?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks after the payment.
Q3. Do you have any MOQ limit for filter cartridge?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for filter cartridge?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on filter cartridge product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
