Realan Desktop Mini ITX Motherboard LR-E240TN AMD E240 Single-core 1.5GHz

FOB Price

Negotiable / Piece

50 Pieces(Min. Order)

Port shenzhen (shekou yantian)
Payment TermsT/T D/P D/A Money Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Products Status	Stock	Application	Desktop
Chipset Manufacturer	AMD	Form Factor	Mini-ITX
Memory Type	DDR3	Graphics Card Type	Integrated
Hard Drive Interface	SATA	Brand Name	e.mini
Model Number	LR-E240TN	Place of Origin	Guangdong, China

Product Description

Specifications

AMD-E 240TN high-speed single-core processor
AMD Radeon HD6310M
8GB DDR3 desktop motherboard
mini itx motherboard hdmi vga

Realan Desktop Mini ITX Motherboard LR-E240TN AMD E240 Single-core 1.5GHz

Quick Reference:

Model	LR-E240TN
CPU	AMD-E240 single-core 1.5GHz
Integrated Graphics	AMD HD6310 support DX11
Chipset	A55E
LAN	1*Realtek 8111E, 10/100/1000M Ethernet controller
Sound Chip	ALC662 2/4/5.1 channel output
Onboard Interface	2MINI PCIE, 2SATA, 1*SIM
Memory	Support 8GB DDR3 1333
USB	4*USB 2.0

Competitive Advantages:

1.AMD-E 240TN high-speed single-core processor

2.AMD Radeon HD6310M high-definition 3D display chip

3.Support 8GB DDR3 1333MHz memory expansion

4.Japanese Lower ESR Solid Capacitor

5.4 COM ports expansion

6.10/100/1000M ethernet controller

7.Support wireless wifi/bluetooth module & 3G-SIM card expansion

8.High-speed SSD, SATA 3Gb/s interface expansion

9.High-Definition HDMI Display Output

10.Support multi-system

11.Self-powered M/B, energy saving

Why Realan:

We are a very professional manufacturer for mini computer cases and power supplies, with the rich experience for over 10 years of developing and producing pc cases. Determination achieves quality, Realan is always keeping the production philosophy that doing by heart, win to win, providing the higher products value cooperation. And our products have been exported to East Asia, Southeast Asia, Middle East, North America, South America, Europe, Africa, Australia and other countries.
Please don't hesitate to contact us if you have any questions or concerns before or after your purchase. We are committed to your 100% satisfaction.

Detailed Specifications:

Model	LR-E240TN
CPU	AMD-E240 single-core processor (1.5G)
Chipset	I/O chipset A55E
Memory	1*SO-DIMM DDR3 1333MHz, Support 8GB memory
Front I/O Interface	2 sets of USB pin, for 4USB2.0; 2 fan connectors, for CPU fan and system fan; 1 Audio pin; 4COM pin; 1 12PIN VGA; 1 * 7PIN PS2; 1LVDS pin (optional); 1HDMI pin (optional)
BIOS	AMIBIOS 4/8Mbit flash memory
O/S	Windows XP, Windows 2000, Linux, Win CE, Windows 7, Windows 8
Operating Temperature	0°C ~ 50°C
Graphic Display	AMD HD6310 support DX 11
Expansion Slot	1*SIM
MINI_PCIE	2
Serial ATA	2*SATA
LAN	1* Realtek 8111E, 10/100/1000M ethernet controller
Sound Chip	ALC662 2/4/5.1channel output
Rear I/O Interface	4* USB2.0 1* VGA 1* 12V DC input 1* HDMI 1* LAN 1* Audio
Monitoring and Management	Wake On LAN System power management Thermal & voltage management Fan speed monitoring
Working Environment Humidity	0% ~ 95% (relative humidity, non-condensing)
Type	MINI-ITX (4*PCB) 170mm x 170mm
Special Performance	without

Graphic Display		Description
Display Chip & Core		AMD Radeon HD6310
Interface Type	VGA	DB15
	LVDS	1*30Pin outlet (24bit) two-channel (optioanl)
	DVI	without
Display Mode	Dual-display	Support dual display mode (replication model, expansion mode) (DOS display)

Audio	Description
Audio Codec	Realtek ALC982

Pin Type

2.54mm 2*5pin header

LAN	Description
LAN Card	Realtek RTL8111E
Function	10/100/1000Mbps self-adaption, support PXE guide and wake on lan
Interface Type	RJ45
Lan Card Lamp	--

USB	Description
Interface Type	USB2.0/1.1
Rare Interface	4

Interface and Pin Type

2*5Pin header/2.54mm

Hard Disk Interface	Description
Interface Type	2*SATA Port
Pin

COM	Description
COM Function	4* com port
COM Position	4*Pin

Power Supply Type and Mode	without
Pin and Interface Type	without
IR and POWER1	without
