SILENT DIESEL GENERATOR DG6500LDE-N (OPENABLE TYPE)

Name: SILENT DIESEL GENERATOR DG6500LDE-N (OPENABLE TYPE)
Brand: Shark or customer brand
SKU: 133028811
Availability: InStock

US$ 200 - 700 MOQ: 5 Sets

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Shark or customer brand

Model Number:

DG6500LDE-N

Changzhou Shark Power Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name Shark or customer brand

Model Number DG6500LDE-N

Output Type AC Single Phase

Speed 3000/3600 RPM

Frequency 50/60HZ

Rated Power 4.5/5KVA

Rated Voltage 110,115,120,220,230,240,110/220,115/230,120/240

Rated Current DC 8.3A,12V

Model	DG6500LDE-N
Rated frequency[Hz]	50 60
Rated voltage[V]	110,115,120,220,230,240,110/220,115/230,120/240
Rated output power[KVA]	4.5 5
Max output power[KVA]	5 5.5
Rated rotation speed[rpm]	3000 3600
Power factor[cosΦ]	1
Phase number	Single phase
Noise level[db(A)@7m]	70-74
Excitation mode	Self-exciation brushless or brush
Engine model	SH186FA/E
Engine Type	Single cylinder,4-stroke,air-cooled,direct injection,diesel engine
Displacement[ml	418
Compression ratio	19:1
Rated output power[KW(Hp)/rpm]	6.0/3000 6.7/3600
Starting system	CL: recoil starter E: Electric starter
Rotation direction(Viewed from flywheel)	Closkwise
Fuel	0#(summer) - 10#(winter)-20#(chillness) diesel
Lube	CD grade or SAE10W-30, 15W-40
Low oil pressure alert system	With
Overall dimension(LxWxH)[mm]	950x565x750
Dry weight[kg]	160 electric
