Amsky offset pringting machine UV CTP machine

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Amsky thermal CTP machine Ausetter 800 series

Product Description

Competitive Advantage:

1. Dynamic Autofocus

2. Fast Balance &Auto Switch of Laser Beam

3. Auto Constant Thermostatic Control of Laser Chassis

4. Technology of DDS Frequency Multiplication and Drum Auto Balance

5. Accurate Graphic Size Calibration

Amsky Ausetter 800 Series Technical Specifications

Mode	U864
Exposing Method	External Drum
Imaging System	64-channel
	Discrete 400-410nm laser
Output Speed	28 plates/hour
	1,030×800mm 2,400dpi
Plate Size	Max.1,130×920mm,Min. 400×300mm
Exposing Size	Max.1,130×904mm
Media Type	UV plate, high-sensitive PS plate
Plate Thickness	0.15mm~0.3mm
Resolutions	2,400dpi
Repeatablity	±5μm(Continuous exposure over four times on the same plate with a temperature of 23℃ and 60% RH )
Interface	USB2.0/USB3.0(Recommended option is USB2.0)
Plate Loading	First manual, then autoload
Net Weight	900KG
Device Size	2,530×1,050×950mm(W×D×H)
Power supply	Single phase:200V-240V; Max power(Peak value):4KW
Environment	Recommended temperature: 21-25℃ Allowable temperature: 18-26℃ Humidity: <70%

Amsky CTP machine picture:
