PU Roller Making Machine Polyurethane Elastomer Casting Machine
- 10 Set / Sets per Month
- Shanghai / Ningbo etc
Product Details
Condition: | New | Product Type: | Other, Machine Cast Polyurethane Elastomers | Brand Name: | DENONPU |
Model Number: | PUM-2E01 | Voltage: | 380V, 50Hz | Power(W): | 28KW |
Dimension(L*W*H): | 3080x1450 x2480 | Weight: | 1.5 Ton | Warranty: | One year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
1. Application field: Manufacture various PU rollers, wheels, sheet, stick, sieves etc;
2. Chemical material: TDI/MDI/NDI/HDI/IPDI etc prepolymers and MOCA/1,4- butanediol etc curing agents;
3. Components and capacities: 2 or 3 even more components, 0.25-0.8Kg/min, 1-3Kg/min, 2-5Kg/min, 3-8Kg/min, 5-15Kg/min etc;
4. Temperature types: High/Middle/Low temperature ranges for choices according to different chemical systems;
5. Multicolor products manufacture: additional color paste adding systems selectable.
polyurethane elastomer casting machine
1. More than 20 years PU equipments industry experience;
2. Advantaged production equipments and modern industrial workshops;
3. Strong R & D team and skilled assembly workers;
5. Strict quality control and perfect after-sales service.
polyurethane elastomer casting machine
1. Free to visit, introduce, do Selection Guide;
2. Free to visit home clients to know in-service condition of machine;
3. Test and adapt whole setting data here as according clients’demands;
4. Send experienced engineers to guide installation, operation, debugging and maintain;
5. Rich supporting suppliers of molds, chemical and others for reference.
polyurethane elastomer casting machine
1.Export standard plywood cases for better care when transport;
2.Ocean shipping, air transportation or land transportation for choices.
Construct:
Included of electric control system, mixing head, chemical tanks, metering pumps, conditioning controller of temperature, rotational speed and pressure display, cleaning system, air washing system, vacuum system and bed frame etc.
Configuration:
Taiwan TCG motors, JINGWEI metering pumps, CHINT or Schneider electrical elements, SANCH frequency controllers, XINJIE PLC and touch screen etc, most of them can be customer designed according to demands.
Working Condition (MOCA curing agent for example):
Mixing Ratios: 100:5-20 for Prepolymer and MOCA;
Processing Temperatures: 80-100 degrees Celsius for prepolymer, 100-120 degrees Celsius for MOCA.
polyurethane elastomer casting machine
