Ultra Fine Air Separation Pulverizer
I. Ultra Fine Air Separation Pulverizer Usage and Application
The Ultra Fine Air Separation Pulverizer is widely applying in various industries such as mining, construction materials, chemical industry, medicine, feedstuff etc. It can be used to have a comminuting process to several hundreds of non-flammable & non-explosive materials with Moth's Hardness are below 7 and humidity is no more than 10%. The output size can be adjusted from 30 to 525 meshes.
II. Ultra Fine Air Separation Pulverizer Working Principle
When material is evenly fed into a crushing chamber, the main shaft rotates in high speed. The material will be comminuted with the aid of impact of main shaft cutter blade and casing interior lining panel and the shorn of high pressure airflow, after that, the material comminuted will via a chamber enter into a separator for re-grading treatment, the coarse material will return to the crushing chamber via a return nozzle for re-pulverization, while the finished material will enter into a powder collector via a draught fan for bagging and packing purpose, the rest airflow will be exhausted via a device which is used for dedust and exhaust.
III. Ultra Fine Air Separation Pulverizer Main Specification
Specification |
GXF400 |
GXF700 |
Feeding Size (mm) |
50 |
50 |
Final products (Mesh) |
30-525 |
30-525 |
Capacity (kgs/h) |
100-800 |
200-2500 |
Main Shift Speed(r/m) |
2900 |
2300 |
Overall Dimension (m) |
4.6×2×4.3 |
12×2.5×4.5 |
Weight (ton) |
1.5 |
3.0 |
Motor power(KW) |
Y160L-2-18.5 |
Y200L-2-37 |
Blower power(KW) |
Y112M-2-4 |
Y1322S-2-7.5 |
About Us:
With more than twenty years' history, Zhengzhou Great Wall Heavy Industry Machinery Co.,Ltd. is a manufacture which specialized in R&D, manufacturing and selling big and middle size heavy industry machinery. Since establishment, we make a good image in the market with scientific management, qualified products and perfect service.
Our main products are crushers, grinding mills, other equipments for crushing plant and grinding plant, as well as building construction equipments. They are widely used in mining, building material, metallurgy, chemical, traffic, reservoir and so on. Our products are not only sold well in more than twenty provinces and cities in China, but also in tens of countries and regions in Eastern Europe, Middle East, Asia, Africa, North America, South America, and Oceania.
Now we have domestic top ranking production equipments and precise testing instrument, each process of products is strictly inspected to guarantee the products to achieving high ex-factory standard. Besides, we cooperate with many famous universities and scientific research institutions, so that can make technical warrantee for the products in it's developing, updating and improving.
"persons of ability guarantee the quality". Our company takes in persons of ability and gives training to the staffs annually to their quality and skill to meet the development of the company.
With the right of importing and exporting, the company owns an international trading department which is specialized in sales and exports, we provide the best service to the foreign clients.
During the past years, we stick to "honest, truth-seeking, innovation and hard working". To keep "Great Wall" brand, we will improve ourselves and try our best to make perfect products and the best service.
Do not hesitate send us inquiry for more details about the Ultra Fine Air Separation Pulverizer.
