Help CenterVSI Sand Making Machine - Great Wall
Related Products
Specifications
VSI Sand Making Machine1Germany authoritative experts' design
2Widely used
3Thinning oil lubricant
4Automatic maintenance
VSI Sand Making Machine
Introduction
Great Wall VSI Sand Making Machine adopts Germany authoritative experts’ design, connecting with World present working conditions. It’s the high-efficiency sand making equipment with advanced world levels in China. The VSI Sand Making Machine is preferred by artificial sand making and stone reshaping industry. It specially provides the best material for the highway, high-speed railway, high-rise buildings, municipal works, hydro-electric dam and concrete mixing station. It ranks first among similar products with its excellent cost performance and reliability.
Application
1. Pebble, rock (the limestone, granite, basalt, grey aluminum ore, landsite, etc.), ore tailings, artificial sand production.
2. Building aggregate, highway, cushion, asphalt concrete and cement aggregate production.
3. Sand making production and stone reshaping production in water conservancy and hydropower engineering field, highway, railway, bridge, passenger line, airport runway, municipal engineering and high-rise buildings.
4. The grinding anterior fine process of mining areas. Building materials, mining, metallurgy, chemical, cement, abrasive, refractory material, etc.
5. The crush of high abrasive materials resistance and secondary disassembly, desulphuration of thermal power and metallurgy, slag and construction waste.
Features and Technical advantages
1. Large handling capacity and High output—60-520t/h, the output of VSI has been stably increased 30% comparing with the traditional equipment under the same motor power.
2. Low wearing parts consumption—Perfect impact angle design of the crushing cavity, less friction against the wearing parts. The operation cost reduces 40%.
3. Perfect product shape — Cubic products, suitable proportion and adjustable fineness modulus. It fits especially man-made sand and stone reshaping. The effect of making and reshaping sand has been increased 30% compared with the traditional equipment.
4. Hydraulic devices are maintained easily—Hydraulic door-opened device make the repair in the crushing cavity easily .Shorten downtime and save effort.
5. Automatic test, safe and reliable—Vibration display and warning device are set. The machine will be warned to stop working when abnormal phenomenon appears.
6. Thinning oil lubricant and automatic maintenance—The original German thinning oil lubricant station, double-pump injection system guarantees the oil supply. The machine will stop automatically when there is no oil and pressure. Water cools the oil and electric motor is heated in winter.
7. Easy installation and operation—Light weight, various forms of installation, movable installation. Easy installation, repair and maintenance. Once the specific use is cleared, VSI crusher can maximize its excellent performance by only minor adjustment.
8. Multi-functions and Flexible application—Due to the unique feeding crushing structure and various kinds of crushing cavities. It is easy to change “rock-rock” to “rock-iron”. So that it achieves the multi-use in one machine. If customers want to change the function of the machine, without making big adjustment, the machine can satisfy customers’ various need.
Model |
VSI-7611 |
VSI-8518 |
VSI-9526 |
VSI-1140 |
||
Capacity |
Center and Sides Feeding |
120-180 |
200-260 |
300-380 |
450-520 |
|
Center Feeding |
60-90 |
100-130 |
150-190 |
225-260 |
||
Max. Feeding Size (mm) |
Soft Material |
35 |
40 |
45 |
50 |
|
Hard Material |
30 |
35 |
40 |
45 |
||
Rotation Speed(rpm) |
1700-1890 |
1520-1690 |
1360-1510 |
1180-1310 |
||
Double Motor Power (kw) |
110 |
180 |
264 |
400 |
||
Overall Dimension |
3700×2150×2100 |
4140×2280×2425 |
4560×2447×2778 |
5000×2700×3300 |
||
Weight (t) |
7.8 |
10.3 |
16 |
25.6 |
||
Vibration Sensor |
Inspection scope: 0.1-20mm/s continual adjustment |
|||||
Hydraulic oil pump |
Motor Power of Double Oil Pump(Kw) |
2×0.31kw |
||||
Overall Dimension |
820×520×1270 |
|||||
Power of Oil Tank Heater |
2KW |
|||||
