Specifications
1.Payment & Shipping Terms:T/T L/C2.Minimum Order :1 set
3.Delivery Time: within 20days working time
die cutting press
JIAYUJ-3/50.60.80.100.150.200 Precision Hydraulic Four-column Plane Die Cutting Machine
Usage and characteristics
1. The machine is widely applicable for cutting of nonmetal materials in various industries by die cutter. For example leather, rubber,plastic, plastic packing, textile and chemical fibre etc.
2. Adopt double oil cylinder, four-column,precise double-crank connecting rod mechanism, which can guarantee that the cutting depth at every cutting position is same.
3. With special setting mechanism, and equipped with die cutter and cutting depth setting, the travel adjustment is simple and accurate.
4. The pressing board of cutting carries out slow cutting when it contacts the die cutter, which can make that there is no size error between the uppermost layer and lowermost layer of cut materials.
5. The central oil supply automatic lubricating system guarantees machine precision and prolongs service life of machine.
6. The operation is labor-saving and simple, with low malfunction, strong cutting power and high cutting speed.
7. Operation with two hands makes high safety.
Main technical parameters
Maximum cutting force |
50/60Tons |
80/100Tons |
150/200Tons |
|
Distance from upper pressing board to worktable |
60-210mm |
60-240mm |
|
|
Size of the upper pressing board Cutting area |
1600×780mm |
1600×960mm |
|
Main motor power |
4kW |
5.5kW |
11 kW |
Electric Supply Voltage |
3x440/400/380/220/200V ,50/60 Hz |
||
Total weightapproximate |
3500kg |
5000kg |
10000kg |
Remark:We can make the machine according to your specifical order ,for example the color,the motor information ,the working table etc.
