Water Proof 7/16 DIN Type rf Coaxial Cable Connector
Negotiable
MOQ: 50 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Anhui, China
Brand Name:
SETSAIL
Model Number:
YF-CNTR
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai for RF 7/16 DIN Type rf coaxial cable connector
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Anhui, China
Brand Name
SETSAIL
Model Number
YF-CNTR
Specifications
RF 7/16 DIN Type rf coaxial cable connector1. Manufacturer
2. Samples available
3. Competitive price,high quality
4.OEM
Water Proof RF 7/16 DIN Type rf coaxial cable connector
Product Name | RF 7/16 DIN Type rf coaxial cable connector | |
Interface | According to IEC 60169-16 | |
Electrical
| Characteristic | 50 ohm |
Frequency Range | DC-3GHz | |
VSWR | <=1.15 | |
Dielectric Withstanding Voltage | >=2500V RMS,50Hz,at sea level | |
Dielectric Resistance | >=5000Mohms | |
Contact Resistance | Center Contact <=1.0Mohms Outer Contact <=0.25Mohms | |
Mechanical | Durability | Mating cycles >=500 |
Material and Plating
| Body | Brass Ni or Tri-Alloy |
Insulator | PTFE | |
Center Conductor | Phosphor Au or Ag | |
Coupling Nut | Brass Ni | |
Temperature | -40°C~+85°C | |
