RF BNC/TNC/N/DIN Cable Connectors for IBS & BTS
Negotiable
MOQ: 50 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Anhui, China
Brand Name:
SETSAIL
Model Number:
YF-CNTR
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
N-male to N-male rf AdapterNegotiableMOQ: 50 Pieces -
N-female to N-female rf Adapter ConnectorNegotiableMOQ: 50 Pieces
-
N-Female Waterproof Connector for RF ComponentsNegotiableMOQ: 50 Pieces
-
N-F/M, DIN Type RF CONNECTORNegotiableMOQ: 50 Pieces
-
rf Adapter Din Male to N MaleNegotiableMOQ: 50 Pieces
Place of Origin
Anhui, China
Brand Name
SETSAIL
Model Number
YF-CNTR
RF BNC/TNC/N/DIN Cable Connectors
Product Name | RF Connector | |
Interface | According to IEC 60169-16 | |
Electrical
| Characteristic | 50 ohm |
Frequency Range | DC-3GHz | |
VSWR | <=1.15 | |
Dielectric Withstanding Voltage | >=2500V RMS,50Hz,at sea level | |
Dielectric Resistance | >=5000Mohms | |
Contact Resistance | Center Contact <=1.0Mohms Outer Contact <=0.25Mohms | |
Mechanical | Durability | Mating cycles >=500 |
Material and Plating
| Body | Brass Ni or Tri-Alloy |
Insulator | PTFE | |
Center Conductor | Phosphor Au or Ag | |
Coupling Nut | Brass Ni | |
Temperature | -40°C~+85°C | |
