N-Type 20W Fixed Coaxial Attenuator
- 20000 Piece / Pieces per Month
- FOB Shanghai
- T/T Credit Card
You May Like
Product Details
Place of Origin | Anhui, China | Brand Name | SETSAIL | |
Model Number | YF-ATT-3G-(3-60)-5W-NSF |
Standart Export cartons for coaxial attenuator
Product Description
Specifications
1.Manufacturer of Fixed Coaxial Attenuator2. 20W coaxial attenuator
3. VSWR:1.2:1 .
4. DC-3GHz coaxial attenuator
Fixed Attenuator
Attenuator is an electronic device which reduces signal power without appreciably distorting its waveform. Working in the opposite way of amplifiers which provide gain, attenuators actually kill gain.
Today, RF attenuators are widely applied in radio frequency signal conditioning and level control areas. They can be used to reduce the amplitude of an RF signal, match the impedances of sources and loads, and measure the gain or loss of a passive device made from voltage divider networks.
According to the technology they use, RF attenuators have three types: fixed attenuators, variable attenuators and switched attenuators.
N-Type 20/30W Fixed Coaxial Attenuator
Product Name | 20/30Watts Coaxial Attenuator
| ||||||
Model Number | YF-ATT-3G-(3-60)-30W-NSF | ||||||
Operating Frequency( GHz ) | DC-3.0 | ||||||
Impendence( Ohm ) | 50 | ||||||
VSWR | ≤1.20:1 | ||||||
Application | Indoor | ||||||
Average Power ( W ) | 20 or 30 | ||||||
Attenuation( dB ) | 3-6 | 10 | 20 | 30 | 40 | 50 | 60 |
Tolerance( dB ) | ±0.5 | ±0.8 | ±1.0 | ±1.2 | ±2.0 | ±2.5 | ±3.0 |
Interface | N (M) - N (F) | ||||||
Operating Temperature( °C ) | -40 ~ + 80 | ||||||
Dimensions( mm ) | See Below Outline Drawing | ||||||
Connector Material | Brass | ||||||
Outer Contact Plating | Black |
