Specifications
Mini StoneCrusher1. Simple structure
2. Easy operation
3. High crushing ratio.
4. Low investment cost and high reliability.
"Great Wall Make Great Machine"
Different Colors&Packages are avaialble
Other HOTEST MODELS For View
ISO9001:2008 Approved,For test report details,pls contact "GreatWall"
Mini StoneCrusher
I. Usage and Application
Small Scale Crusher is widely used in the industry of mining, building materials, chemical industry, metallurgy and fodder. It can crush materials with middle or less than middle hardness into secondary of fine granularity. Such as, barite, limestone, terrazzo, silica sandstone, coal, coke, gypsum, aluminum sulfate, slag, etc.
II. Working Principle and Features
The electric motor drives the rotor and the rotor moves, making the hammer rotate in high speed. The materials are crushed in the crusher by the rotated hammer. The end products come out via the strips of the screen under the machine. The size of the granularity can be adjusted by changing the gap among the screen strips. The advantages of the machine are simple in operating, high in productivity, and very low investment cost.
III. Main Specifications
Small Hammer Crusher
Model |
Max. Feeding |
Output |
Capacity |
Motor Power |
Weight |
PC400×300 |
100 |
<15 |
3-10 |
11 |
0.86 |
PC600×400 |
120 |
<15 |
8-15 |
22 |
1.55 |
PC800×600 |
150 |
<20 |
10-40 |
55 |
4.8 |
PC1000×800 |
200 |
<30 |
16-65 |
110 |
8.1 |
PC1300×1200 |
280 |
<40 |
50-200 |
240 |
14.8 |
PC1600×1600 |
350 |
<50 |
100-350 |
480 |
37.5 |
Model |
Feed Opening Size |
Max. Feeding Size |
Adjustable Range of Output Size |
Capacity |
Motor Power |
Weight |
Overall |
PE250×400 |
250×400 |
200 |
20-50 |
5-20 |
15 |
2.9 |
1430×1310×1340 |
PE400×600 |
400×600 |
350 |
40-100 |
15-60 |
30-37 |
6.8 |
1700×1732×1653 |
PE500×750 |
500×750 |
425 |
50-100 |
40-100 |
45-55 |
11.2 |
2035×1921×2000 |
PE600×900 |
600×900 |
480 |
65-160 |
60-140 |
55-75 |
16.5 |
2290×2206×2370 |
PE750×1060 |
750×1060 |
630 |
80-150 |
80-230 |
90-110 |
29 |
2655×2302×3110 |
PE900×1200 |
900×1200 |
750 |
95-165 |
140-320 |
110-132 |
54.5 |
3789×3050×3025 |
PE1000×1200 |
1000×1200 |
850 |
105-185 |
180-400 |
160-200 |
56.5 |
3900×3320×3280 |
PE1200×1500 |
1200×1500 |
1020 |
150-300 |
250-650 |
220-250 |
99.6 |
4300×3540×4043 |
PEX150×250 |
150×250 |
125 |
10-40 |
1-3 |
5.5 |
0.85 |
896×745×935 |
PEX150×750 |
150×750 |
125 |
12-45 |
5-16 |
15 |
3.8 |
1205×1495×1203 |
PEX250×750 |
250×750 |
210 |
25-60 |
10-40 |
22-30 |
5 |
1667×1545×1020 |
PEX250×1000 |
250×1000 |
210 |
25-60 |
15-50 |
30-37 |
6.8 |
1964×1550×1380 |
PEX250×1200 |
250×1200 |
210 |
25-60 |
20-60 |
37-45 |
8.5 |
2192×1605×1415 |
PEX400×1200 |
400×1200 |
320 |
35-95 |
28-95 |
45-55 |
11.7 |
2256×2100×1960 |
JCE1302 |
180×1300 |
150 |
10-30 |
12-50 |
30-37 |
6 |
1320×2150×1175 |
JCE1003 |
250×1000 |
220 |
20-40 |
15-65 |
30-37 |
5.6 |
1400×1850×1310 |
JCE1303 |
250×1300 |
220 |
20-40 |
26-85 |
37-45 |
6.8 |
1450×2150×1175 |
JCE604 |
400×600 |
350 |
35-85 |
15-85 |
30-37 |
10 |
1920×1460×1840 |
About Us:
With more than twenty years' history, Zhengzhou Great Wall Heavy Industry Machinery Co.,Ltd. is a manufacture which specialized in R&D, manufacturing and selling big and middle size heavy industry machinery. Since establishment, we make a good image in the market with scientific management, qualified products and perfect service.
Our main products are crushers, grinding mills, other equipments for crushing plant and grinding plant, as well as building construction equipments. They are widely used in mining, building material, metallurgy, chemical, traffic, reservoir and so on. Our products are not only sold well in more than twenty provinces and cities in China, but also in tens of countries and regions in Eastern Europe, Middle East, Asia, Africa, North America, South America, and Oceania.
Now we have domestic top ranking production equipments and precise testing instrument, each process of products is strictly inspected to guarantee the products to achieving high ex-factory standard. Besides, we cooperate with many famous universities and scientific research institutions, so that can make technical warrantee for the products in it's developing, updating and improving.
"persons of ability guarantee the quality". Our company takes in persons of ability and gives training to the staffs annually to their quality and skill to meet the development of the company.
With the right of importing and exporting, the company owns an international trading department which is specialized in sales and exports, we provide the best service to the foreign clients.
During the past years, we stick to "honest, truth-seeking, innovation and hard working". To keep "Great Wall" brand, we will improve ourselves and try our best to make perfect products and the best service.
Do not hesitate send us inquiry for more details about the Mini StoneCrusher.
