Help Center698-2700MHz, RF 2-way Power Divider
Related Products
-
800-2700MHz, RF GSM Splitter/DividerUS$ 1 - 50MOQ: 1 Piece -
800-2500MHz, RF GSM Splitter/DividerUS$ 1 - 50MOQ: 1 Piece
-
RF Microwave Cavity Power Splitter/Divider(800-2500MHz)DIN-FNegotiableMOQ: 20 Pieces
-
Power Splitter 3 Ways SETSAILNegotiableMOQ: 50 Pieces
-
3-Way Power Splitters SETSAILNegotiableMOQ: 50 Pieces
Specifications
1. We are Manufacturer of RF Power Splitter2. OEM Service is ok
3. 500pcs in stock
4. ISO9001:2008
5. Competive Prices.
Applications: 698-2700MHz, RF 2/3/4 way Power Splitter
1. Mobile Communication Network Optimization and In-door distribution system.
2. Cluster communication, satellite communication, shortwave communication and hopping radio.
3. Radar, electronic navigation and electronic confrontation.
4. Aerospace equipment systems.
Technical Specifications:
Model |
YF-CP-0727-02-NF |
YF-CP-0727-03-NF |
YF-CP-0727-04-NF |
Frequency(MHz) |
698-2700MHz |
||
Insertion Loss(dB) |
3.4 |
5.6 |
6.5 |
PIM(dBc) |
-140dBc@2*43dBm |
||
VSWR |
1.25:1 |
||
Power Capacity(W) |
200 |
||
Impedance(ohm) |
50 |
||
RF Connector |
N-female |
||
Application |
Indoor or Outdoor |
||
Operating Temperature |
-35~+60 |
||
Color |
Black-plated |
||
Relative Humidity |
5%-95% |
||
800-2500/800-2700/700-2700/670-2700MHz, 2/3/4 way RF Cavity Power Splitter
700-2400MHz, SMA-female, RF 4-way Power Splitter/Divider
800-2500/800-2700/700-2700/670-2700MHz, 2/3/4 way RF Micro-strip Power Splitter
800-2500/800-2700/700-2700/670-2700MHz, 5/6/7/8/10/13/15/20/25/30/40dB Directional Coupler
1-200W Dummy Load/Termination
1-200W RF Coaxial Attenuators
