Specifications
1.Manufacturer of 3 ways cavity Power dividers2. 700-2700Mhz,DIN-Female.
3. OEM services
4. Two years warranty
Technical Specification:
3-Way 7/16 DIN Female 700-2700MHz Cavity Power Dividers
Product Name |
2-way power dividers |
3-way power dividers |
4-way power dividers |
Model |
YF-PS-0727-02-DIN |
YF-PS-0727-03-DIN |
YF-PS-0727-04-DIN |
Frequency |
700-2700MHz |
||
Insertion loss(dB) |
3.3 |
5.4 |
6.5 |
Color |
Black-plated |
||
VSWR |
1.30:1 |
||
Power Capacity (W) |
500 |
||
3rd order PIM |
-150dBc@2×43dBm |
||
Impedance(ohm) |
50 |
||
Temperature(deg) |
-35 deg to +60 deg |
||
RF connector |
DIN-female |
||
Relative Humidity |
5%-95% |
||
Size(mm) |
2210.1×60.4×20 |
223.4×60.4×18 |
223.4×60.4×18 |
Wight(kg) |
0.17 |
0.21 |
0.235 |
Applications:
1. Mobile Communication Network Optimization and In-door distribution system.
2. Cluster communication, satellite communication, shortwave communication and hopping radio.
3. Radar, electronic navigation and electronic confrontation.
4. Aerospace equipment systems
