Help Center800-2500MHz, RF 3-way Power Divider/Splitter (IBS Used)
Related Products
-
800-2500MHz, RF 4-way Cavity Power Divider/Splitter (IBS Used)NegotiableMOQ: 1 Piece -
800-2500MHz,2/3/4 Way IBS RF Power SplitterNegotiableMOQ: 5 Pieces
-
698-2700MHz, Silvery-white RF Power Splitter (2-way, Cavity)NegotiableMOQ: 5 Pieces
-
698-2700MHz, Silvery-white RF Singal Booster Splitter (3-way, Cavity)NegotiableMOQ: 5 Pieces
-
698-2700MHz, Silvery-white Video Singal Splitter/Divider (4-way, Cavity)NegotiableMOQ: 5 Pieces
Specifications
1. We are Manufacturer of RF Power Splitter2. OEM Service is available
3. 1000pcs in stock
4. Power Splitter with Best Price
Applications:
Power Splitter: 800-2500MHz, N-female, 200W, 3-way, Cavity-type, Low PIM3
Used in IBS and BTS projects
1. Mobile Communication Network Optimization and In-door distribution system.
2. Cluster communication, satellite communication, shortwave communication and hopping radio.
3. Radar, electronic navigation and electronic confrontation.
4. Aerospace equipment systems
800-2500MHz Cavity Power Splitters (N-female Connector, 200W, PIM3=-140dBc)
Technical Specification:
Model |
YF-CPS-0825-02-NF |
YF-CPS-0825-03-NF |
YF-CPS-0825-04-NF |
||
Frequency(MHz) |
800-2500 |
||||
Insertion loss(dB) |
3.3 |
5.4 |
6.5 |
||
| Color | Black-plated |
||||
VSWR |
1.25:1 |
||||
Power Capacity (W) |
200 |
||||
3rd order PIM |
-140dBc@2×43dBm |
||||
Impedance(ohm) |
50 |
||||
Temperature(deg) |
-35 deg to +60 deg |
||||
RF connector |
DIN-female |
||||
Relative Humidity |
5%-95% |
||||
Size(mm) |
2210.1×60.4×20 |
223.4×60.4×18 |
223.4×60.4×18 |
||
Wight(kg) |
0.17 |
0.21 |
0.235 |
||
