Help CenterGSM900/DCS1800/UMTS2100MHz Three Band Combiner (Manufacturer)
Related Products
-
GSM900/DCS1800/UMTS2100MHz Tri Band Combiner (Manufacturer)NegotiableMOQ: 1 Piece -
DCS/WCDMA RF Dualband Combiner (1710-1880/1920-2170MHz)US$ 1 - 100MOQ: 1 Piece
-
GSM900/DCS1800/UMTS2100 Triplexer CombinerUS$ 1 - 200MOQ: 1 Piece
-
RF GSM&DCS/3G Dual-band CombinerNegotiableMOQ: 5 Pieces
-
RF Duplexer/Dual-band Combiner (GSM/TD-SCDMA)NegotiableMOQ: 10 Pieces
Specifications
Three Band Combiner1.We are good manufacturer
2.Low Insertion loss and low VSWR
3.3 years Warranty
4.Competitive price
Applications for Three Band Combiner
1. Mobile Communication Network Optimization and In-door distribution system.
2. Cluster communication, satellite communication, shortwave communication and hopping radio.
3. Radar, electronic navigation and electronic confrontation.
4. Aerospace equipment systems.
GSM900/DCS1800/UMTS2100MHz Three Band Combiner
Model |
YFTX-RFCOM-TR-02NC |
||
CH1: GSM |
CH2: DCS |
CH3:WCDMA |
|
Frequency(MHz) |
800-960 |
1710-1880 |
1920-2170 |
Insertion Loss(dB) |
≤0.4dB |
≤0.8dB |
≤0.8dB |
Passband Ripple(dB) |
≤0.2dB |
≤0.6dB |
≤0.6dB |
Outband Rejection(dB) |
≥80@CH2&3 |
≥80@CH1&3 |
≥80@CH1&2 |
VSWR |
1.30 |
||
IM3 |
-120dBC |
||
Impedance(ohm) |
50 |
||
Power(W) |
200 |
||
Operating Temperature(deg) |
-30~+65°C |
||
Connector Type |
N-K |
||
Dimensions(mm) |
216*226*51 (Without Connectors) |
||
Send Inquiry to This Supplier
