Specifications
Great Wall Upgrade Cement Mill1.High grinding ratio
2.Low cost.
3.Easy operation.
4.Top quality
"Great Wall Make Great Machine"
Different Colors&Packages are available
Other HOTEST MODELS For View
ISO9001:2008 Approved,For test report details,pls contact "GreatWall"
Ball Mill Usage and Application
The Ball mill is widely applied in mineral classification, cement,chemical industry,etc.
It can grind all kinds of rocks and grindable materials. This ball mill has two ways of grinding: The dry process and wet process. Our ball mill has been increased about 20% and unit product power consumption has been reduced 10%-12% down.
Ball Mill Features
Ball mill is mainly composed of charging and discharging, cyclone and rotation parts. Hollow axis is made of steel parts with a lining replacable. Major rotation gear, machined by rolling wheel of casting, is lined with wearing plate with fine wear-resistingproperty. This makes the ball mill runs stably and reliably.
Ball Mill Structure
Ball mill is composed of feeding part, discharging part, turning part and driving part (reducer, small driving gear, electric motor and electric control). The quill shaft adopts cast steel part and the liner is detachable. The turning gearwheel adopts casting hobbing process and the drum is equipped with wear-resistant liner, which has good wear-resistance. The ball mill is with stable and reliable working condition. Moreover, according to different materials and discharging methods, there are dry ball mills and wet ball mills for choice.
Ball Mill Main Specifications
|
Item
Model |
Rotation Speed of Cylinder (r/min) |
Loading of Ball (t) |
Feeding Size (mm) |
Output size (mm) |
Capacity (t/h) |
Motor Power (kw) |
Weight (t) |
900×1800 |
38 |
1.5 |
<20 |
0.074-0.8 |
0.65-2 |
18.5 |
3.6 |
900×3000 |
38 |
2.7 |
<20 |
0.074-0.8 |
1.1-3.5 |
22 |
4.6 |
1200×2400 |
32 |
3.8 |
<25 |
0.074-0.6 |
1.5-4.8 |
45 |
12.5 |
1200×3000 |
32 |
5 |
<25 |
0.074-0.4 |
1.6-5 |
45 |
12.8 |
1200×4500 |
32 |
7 |
<25 |
0.074-0.4 |
1.6-5.8 |
55 |
13.8 |
1500×3000 |
27 |
8 |
<25 |
0.074-0.4 |
2-5 |
90 |
17 |
1500×4500 |
27 |
14 |
<25 |
0.074-0.4 |
3-6 |
110 |
21 |
2200×6500 |
21 |
31 |
<25 |
0.074-0.4 |
14-26 |
380 |
52.8 |
We have ball mills with other models
1500×5700 1830×3000 1830×6400 1830×7000 2200×5500 2200×7500 2200×9500 2400×7000 2700×3600 3200×4500 3600×6000
Services:
1.Pre-sales Service
Offering comprehensive technical and business consultation services;
Proposing the most suitable scheme and equipment for our clients;
Designing and fabricating targeted products according to the special requirements of clients;
Training periodically high qualified service technician.
2.After-sales Service
Highly inspecting equipments in every working procedure, quality comes first;
Fast & Safe Delivery;
Assisting our clients for foundation construction of equipments;
Dispatching engineers to install and debug equipments;
Training the first-line operators on site;
Regularly visit clients to solve production problems;
Providing life-long maintenance service;
Providing technical exchanging;
About Us:
With more than twenty years' history, Zhengzhou Great Wall Heavy Industry Machinery Co.,Ltd. is a manufacture which specialized in R&D, manufacturing and selling big and middle size heavy industry machinery. Since establishment, we make a good image in the market with scientific management, qualified products and perfect service.
Our main products are crushers, grinding mills, other equipments for crushing plant and grinding plant, as well as building construction equipments. They are widely used in mining, building material, metallurgy, chemical, traffic, reservoir and so on. Our products are not only sold well in more than twenty provinces and cities in China, but also in tens of countries and regions in Eastern Europe, Middle East, Asia, Africa, North America, South America, and Oceania.
Now we have domestic top ranking production equipments and precise testing instrument, each process of products is strictly inspected to guarantee the products to achieving high ex-factory standard. Besides, we cooperate with many famous universities and scientific research institutions, so that can make technical warrantee for the products in it's developing, updating and improving.
"persons of ability guarantee the quality". Our company takes in persons of ability and gives training to the staffs annually to their quality and skill to meet the development of the company.
With the right of importing and exporting, the company owns an international trading department which is specialized in sales and exports, we provide the best service to the foreign clients.
During the past years, we stick to "honest, truth-seeking, innovation and hard working". To keep "Great Wall" brand, we will improve ourselves and try our best to make perfect products and the best service.
Do not hesitate send us inquiry for more details about the Great Wall Upgrade Cement Mill .
