Specifications
DS110 push types of electrical switch1.types of electrical switch
2.1a 250vac, 3a 125vac
3.on on, on off
4.CE,CCC,ISO9001
DS110 push types of electrical switch/ Types of electrical switch/ electrical switch
Description:
15 years' experience of manufacturing in this field.
External AppearanceVisual measurement: surface of metals cleanness, no rust stain, no cladding shell off
Temperature-25~ +70°C
Relative Humidity( 40°C) ≤ 95%
Normal Load 1A AC 250V
Withstand VoltageAC250V (50Hz)/1min
Travel 4mm
Service Life 100,000 Cycles
Operating Force 4N
Center Distance2.2mm
Diameter:7mm
Height:21.4mm
Length of Terminal 5.1mm
Width of Terminal 0.5mm
Quantity of Terminals 2
Setup ModeVertical Plug-in
Color of Key :Red
Lock Mechanism Lockless
UsesInstrument,Meter,Household Appliances,
Push button switch, push switch, push switches, electric push switch, mini push switch
Specification:
| Rating | 1A 250V 3A 125VAC |
| Contact resistance |
≤50mΩ |
| Insulation resistance | ≥100mΩ |
| Withstand voltage | 500VAC |
| Switching life | ≥10000cycles |
types of electrical switch, electrical switch, push switch
Contour:
