Specifications
impact crusherSimplify crushing process
Low consumption and cost
High crushing ratio
High capacity and quality
PE Series Impact Crusher Introduce
Our field of business are block machine manufactruring Industries, Crusher manufacturing industries ,Aerated block plants manufacturing indsutires, Road&Building construction machineries,,etc through out China as well as abroad.
1.Brief Introduction of PF Series Impact Crusher
PF series impact crusher is our latest generation of impact crusher in absorbing domestic and international advanced technology, combining the specific industrial conditions of domestic stones industry. It adopts the latest manufacturing technology, the special structural design, processing cubic shaped end products. This machine is used for primary, secondary, fine crushing mining and rocks (for example, granite, limestone, concrete, etc) materials with feeding size less than 500mm and compressive strength less than 350MPa. It is widely used in crushing ores, railways, highways, energy, cement, chemical, building materials and other industries. The output size can be adjusted and the crushing rotor size is variable.
2.Specifications of Impact Crusher
|
Model name |
Size of rotor (mm) |
Feed opening (mm) |
Max. feed size (mm) |
Capacity (t/h) |
Power of Motor (kW) |
Weight (t) |
PF1007 |
Φ1000×700 |
400×730 |
300 |
15-30 |
37 |
6 |
PF1010 |
Φ1000×1050 |
400×1080 |
350 |
50-80 |
75 |
12.5 |
PF1210 |
Φ1250×1050 |
400×1080 |
350 |
70-130 |
110 |
16.5 |
PF1214 |
Φ1250×1400 |
400×1430 |
350 |
90-180 |
132 |
19 |
PF1315 |
Φ1320×1500 |
860×1520 |
500 |
120-250 |
200 |
24 |
PF1320 |
Φ1320×2000 |
860×2030 |
500 |
160-350 |
260 |
27 |
3.Detailed Product Description of Impact Crusher
(1).PF series of impact crusher can process the material with side length of 100 to 500mm. The compression strength can reach 350MPA. The advantages of the products are big reduction ratio and cubic shape of the crushed materials.
(2).PF series of impact crusher is applied to crush the materials with the medium hardness, for example, limestone to be crushed in cement industry. They have the strength of large processing capacity and smaller size of discharging materials.
