Specifications
Joss Paper Furnace for Temple1. Smoke Purification Efficiency: over 95%
2. Usage: burn joss paper and purify its smoke
3 CE
Joss Paper Furnace for Temple
Name |
Joss Paper Furnace for Temple |
Usage |
Burn joss paper and purify its smoke in temples |
Capacity of Joss Paper Incineration |
10 to 30 kg per hour |
Smoke Purification Principle |
Electrostatic precipitator |
Smoke Purification Efficiency |
Over95% |
Material |
Stainless Steel |
Rated Power |
3.3KW |
Power Supply |
200 to 240V/ 50HZ |
Dimension |
1800*1600*2900mm |
Net Weight |
1200KG |
Delivery Time |
90 days after the receipt of payment |
Package |
Plywood crate with polyfoam lining |
QC |
ISO9001:2008 |
Outstanding Features of Joss Paper Furnace for Temple:
1. High temperature resistance brickwork construction of the burning chamber ensures safe to burn joss paper in Joss Paper Furnace for Temple .
2. High dust and smoke removal efficiency. No smoke can be seen at the outlet.
3. With the equipped high efficiency extraction fan, the joss paper can be completely incinerated.
4. The operation and cleaning of the Joss Paper Furnace for Temple are electronic programmable controlled.
5. The needed water can be circulated and discharged directly after final use.
The working Process of Joss Paper Furnace for Temple:
1. Hot dark smoke generated from the burning joss papers is extracted through a U-shaped cooling duct.
2. Smoke will be cooled down and large smoke particles and fume will be removed in the water spraying section.
3.Cooled smoke and the rest of fine dust particles will be collected and fully purified by the specially-designed electrostatic precipitator.
4. The processed exhaust air which is smokeless and clean can be discharged directly via the extraction fan.
One year free repair and lifelong maintenance of our Joss Paper Furnace for Temple are guaranteed.
Our Joss Paper Temple is your wise choice.
Schematic Diagram of Joss Paper Furnace for Temple:
Joss Paper Furnace for Temple
The Installation Site of Joss Paper Furnace for Temple
