Automatic Brick Production Line QT4-15C Hydraulic Concrete Brick Making Machine

Automatic Brick Production Line QT4-15C Hydraulic Concrete Brick Making Machine photo-1
Automatic Brick Production Line QT4-15C Hydraulic Concrete Brick Making Machine photo-2
Automatic Brick Production Line QT4-15C Hydraulic Concrete Brick Making Machine photo-3
Automatic Brick Production Line QT4-15C Hydraulic Concrete Brick Making Machine photo-4
US$ 50,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Hollow Block Making Machine
Brick Raw Material:
Concrete
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Hollow Block Making Machine
Brick Raw Material Concrete
Processing Brick Production Line
Method Hydraulic Pressure
Automatic Yes
Capacity 5000-7000 pieces/day
Place of Origin Shandong, China
Brand Name DONGYUE BRAND
Model Number QT4-15C
Voltage 220V/240V/380V/415V
Power 19.3kw
Dimension(L*W*H) 4000*1800*2800
Certification CE,SGS,ISO,BV
Warranty 12 month
After-sales Service Provided Engineers available to service machinery overseas

automatic brick production line QT4-15C hydraulic concrete brick making machine



automatic brick production line QT4-15C hydraulic concrete brick making machine

QT4-15C automatic press brick making plant is suitable to make road blocks, road-side bricks and river bricks. Adopt sub-storage device and independent storage hopper, this machine can overcome the liquefaction of concrete defects in advance, and ensure the quality of the finial products. It can automatically operate the whole set, from material feeding to finish products output.



automatic brick production line QT4-15C hydraulic concrete brick making machine

1. Parameter of QT4-15C:



Dimension of host machine

3500×2220×2850mm

Host machine power

45.38KW

Moulding area

1025×810mm

Vibration force

100KN

Moulding period

15-25S

Mixer model

JS750

The size of the pallet

1350×900×30mm

General water Consumption

12T/every day

Weight of the host machine

14T



Voltage

Adapt to your local voltage





2. Capacity of QT4-15C:



Size(LxWxH)

Pcs/Mould

Pcs/ Hr

Pcs/ 8 Hr

400X100X200

20

3000-3600

24000-28800

400X150X200

14

2100-2520

16800-20160

400X200X200

10

1500-1800

12000-14400

400X250X200

8

1200

9600



Paver:200X100X60

35

5250

42000



Paver:200X165X60

20

3000

24000



3.Material proportion of QT4-15C:

1). 8-10% cement, 30-40 % sand , 50-60% crushed stone.

 2). 8-10% cement, 30% flyash, 60% sand or stone powder
