Best Selling Cellular Lightweight Concrete Panel Machine of Dongyue
US$ 500,000 - 1,200,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, aac block machine and price
Brick Raw Material:
Sand
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Fly Ash Aac Production Plantby Dongyue Perlite Manual Aac Block Brick Making MachineUS$ 500,000 - 1,200,000MOQ: 1 Set -
Fly Ash Aac Production Plantby Dongyue Perlite Aac Machine PriceUS$ 500,000 - 1,200,000MOQ: 1 Set
-
Fly Ash Aac Production Plantby Dongyue Perlite White Block Aac Making MachinesUS$ 500,000 - 1,200,000MOQ: 1 Set
-
Fly Ash Aac Production Plantby Dongyue Perlite Used Concrete Aac Block Making MachinesUS$ 500,000 - 1,200,000MOQ: 1 Set
-
Aerated Block Equipment Production Line DONGYUEUS$ 500,000 - 1,000,000MOQ: 1 Set
Condition
New
Type
Other, aac block machine and price
Brick Raw Material
Sand
Processing
Brick Molding Machine
Method
Hydraulic Pressure
Automatic
Yes
Capacity
10 sets per month, 50000 cbm-100000 cbm
Place of Origin
Shandong, China
Brand Name
Dongyue
Model Number
aac panel manufacturers dongyue
Voltage
240V/415V
Dimension(L*W*H)
3000*2200*3150mm
Certification
CE
Warranty
12 months
After-sales Service Provided
Engineers available to service machinery overseas
German -China AAC Panel Machinery Manufacturer
Best selling lightweight concrete block and panel machines
1.Introduction of German technology aac block machine for sale aac block manufacturers in gujarat(35 lines abroad,14 lines in India)
Areated concrete block (light block ) is the light and porous buidling material. It has light keeping temperature cant burn and other advantages.it can be made into many kinds of bricks for example:600×200×100,80×80×180,240×115×53,600×200×125),they could be used industry building and common building.they are more and more popular in the world.in the future,they will replace the Clay brick completely.
2.AAC block machine/lightweight block machine advantages
(1)light weight
Areated concrete density is usually 400-700kg/m3,(according the market in produce ),same as 1/3 of clay brick and 1/5 common concrete.So use the Light brick can reduce the weight of the build more,and also reduce the beam of roof and pillar press best.then you can see,it can save the material and cost,it also fighting shaking.
(2) keeping temperature
It has many are porous,the delivery hearting coefficient is 0.9-0.22W/(mk),the same as 1/4 or 1/5 of clay brick,so it is best materials now in the world.There are many kinds material,have lowest waste.
(3)High Strength
High pressure steam-curing autoclaving process gives AAC unmatchable strength to weight ratio, higher than even M150 concrete and far exceeds the Indian Building code requirements
(4)Cost saving
Being lightweight AAC drastically reduces the dead weight of building, resulting into reduction in steel (up to 27%) and cement (up to 20%) structural cost saving.Being 8 times the size of a clay brick, AAC wall construction involves 1/3 the joints, thus an overall mortar saving up to 66%
3.AAC block DETAILED PRODUCT DESCRIPTION
1 Product weight is according to 600kg/m3 to control.
2 annual capacity 200,000M3
3 set raw material proportion: cement 6.5%, raw lime 23%, flyash 68%, gypsum 3%, aluminum paste powder 350g/M3.
4 water and material rate 0.631
5 one mould product 2.88M3
6 Casting slurry cycle time 5-6 minutes, cut cycle time 5 minutes.
7 casting slurry temperature 38-42 degree
8 body quiet stop. Time is 1.5-2.5housr, temperature 50-90 degree, after quiet stop body strength is 0.15-0.18Mpa
9 Steam curing cycle time, come in and out autoclave about 0.5hour, steam curing cycle time about is 6 hours/1.6Mpa, total 6.5 hours.
6. AAC block Market Analysis
AAC is becoming more and more popular around the world, from western countries and then to developing countries. Below Properties make AAC have unmatchable property, especially for high buildings:
1) Extreme Light Weight
2) Large Variety of Sizes
3) High Fire Resistant
4) Excellent Thermal Insulation
5) Great Sound Insulation
6) Moisture Protection
7) Termite Resistant
8) High Workability and Easy Processing
