Help CenterHot Sell CO2 Welding Machine Price MIG-200F (MOSFET Type)
Related Products
-
2013 NEW Design MOSFET Inverter CO2 GAS Shielded MIG Welding MachineUS$ 100 - 500MOQ: 1 Piece -
2013 NEW Design MOSFET Inverter CO2 GAS Shielded MIG-250 Welding MachineUS$ 100 - 500MOQ: 1 Piece
-
Hot Selling Inverter dc Tig-mma-cut Ct520 Welding Machine From ManufacturerNegotiableMOQ: 1 Set
-
2015 Professional Tool TrolleProfessional Tools Set/121pcs Socket Tool Sets Household Tool SetUS$ 8.5 - 89.5MOQ: 500 Sets
-
2015 New Products Wire Stripping Tools Cable Sheath Stripper Power Cable Stripper Hand Tools StripperNegotiableMOQ: 100 Pieces
| Inverter CO2 Gas Shielded CO2 Welding Machine pr Hot sell CO2 Welding Machine price MIG-200F (MOSFET Type) ice | ||||
| Model | MIG-200Y | MIG-250Y | MIG-200F | MIG-250F |
| Type | MOSFET | |||
| Rated input voltage (V) | single phase AC220 ±15% | three phase AC380 ±15% | single phase AC220 ±15% | three phase AC380 ±15% |
| Rated frequency (Hz) | 50/60 | |||
| Rated input current (A) | 23.5 | 10.5 | 23.5 | 10.5 |
| Output current (A) | 180 | 220 | 180 | 220 |
| Output voltage (V) | 23 | 25 | 23 | 25 |
| Duty cycle (%) | 60 | 60 | 60 | 60 |
| Efficiency (%) | 85 | 85 | 85 | 85 |
| Power factor | 0.93 | 0.93 | 0.93 | 0.93 |
| Diameter of wire (mm2) | 0.8 | 1.0 | 0.8 | 1.0 |
| Type of wire feeder | built-in | built-in | separated | separated |
| Net weight of machine(KG) | 33.7 | 35.2 | 11.9 | 13.7 |
| Gross weight of machine packing(KG) | 40 | 41.3 | 13 | 14.8 |
| Gross weight of accessories packing (KG) | — | — | 16.3 | 16.3 |
| Dimension of machine (mm) | 630×315×695 | 630×315×695 | 500×210×370 | 500×210×370 |
| Dimension of packing- machine (mm) | 660×370×750 | 660×370×750 | 560×270×460 | 560×270×460 |
| Dimension of packing-wire feeder (mm) | — | — | 555×435×410 | 555×435×410 |
| including accessories: earth clamp×1pcs, cable joint×1pcs, grounding cable×3meters, pressure regulator×1pcs, MIG torch×1pcs, | ||||
| additional accessories for MIG-200F/MIG-250F: double drive wire feeder×1pcs, control cable×5meters | ||||
Our clients include:
Our competive :
PLS NOTE:
The average of our welding machine lasts between FIVE and SIX years.
If there were problems in seven days,we replace the new one for you.
Why choose ANDELI Brand welding machine?
1. We are welding machine MANUFACTURER,so we can offer better price and after-sale service and shorter delivery date.
2. We use all new components,TOSHIBA mosfet tube,FUJI diode,NICON capacitor and so on imported components.
3. We adopt SMT technology to decrease failure rate and it is convenient to repair the machine and reduce the cost of repairing,we just need to change the bad pcb board.
4. We have successfully exported to Indonesia, Malaysia, and Thailand and so on foreign countries in all more than ten thousand of each model.We all get good feedback.
5. For large order,our engineer can come to your country Site Instruction.
6. We give customer 1% FREE SPARE PARTS (include pcbs with components and additional mosfet tube and components) to support repairment.
7. We provide a FREE ONE YEAR WARRANTY for all our items.
8. OEM brand.
portable aluminum welding machine
Working line:
Price
Send inquiry now,get offer in 24 hours! Even in weekends!
