Inverter CO2 GAS Shielded mig welders for sale MIG-250Y(MOSFET Type)

Specifications

Inverter CO2 GAS mig welders for sale
Low cost but high effciency
can be adjusted for different requirement
small splash

Inverter CO2 GAS Shielded mig welders for sale(MOSFET Type)



MIG CO2 Gas Shielded Welder Machine
Model	MIG-350	MIG-500	MIG-630
Type	IGBT Module
Function	MIG
Rated input voltage (V)	three phase AC380 ±15%
Rated frequency (Hz)	50/60
Rated input power (KVA)	14	25	35
Rated input current (A)	21	38	53
Input protection circuit breaker (A)	40	63	100
Rated working voltage (V)	34	40	45
Output current (A)	60-350	60-500	60-630
Output voltage (V)	15-40	15-50	15-50
Diameter of input power cable (mm3)	≥3×4	90%	≥3×6
Welding cable (mm2)	≥35	≥50	≥70
Diameter of welding wire (mm3)	0.8/1.0/1.2	1.0/1.2/1.6	1.0/1.2/1.6
No-load voltage (V)	50	75	95
No-load loss (W)	100	150	150
Rated duty cycle (%)	80	80	80
Efficiency (%)	85	85	85
Power factor	0.93	0.93	0.93
Wire feeder	separated
Net weight (KG)	40.5	50.3	60.7
Gross weight (KG)	45.5	55.8	73
Housing of machine	iron	iron	iron
Dimension of machine (mm)	645×335×576		700×360×638
Packing	carton/carton		wooden box/carton
Dimension of packing (mm)	machine: 700×390×660         wire feeder: 555×435×410		machine: 760×480×710         wire feeder: 555×435×410
including accessories: earth clamp×1pcs, cable joint×2pcs, gas regulator×1pcs, double drive wire feeder×1pcs, grounding cable×3meters, control line×5meters, MIG torch×1pcs
additional accessories for NB-350S/500S/630S: cable joint×1pcs, inner hexagon spanner×1pcs









PLS NOTE:



The average of our welding machine lasts between FIVE and SIX years.



If there were problems in seven days,we replace the new one for you.







Why choose ANDELI Brand welding machine?



1. We are welding machine MANUFACTURER,so we can offer better price and after-sale service and shorter delivery date.



2. We use all new components,TOSHIBA mosfet tube,FUJI diode,NICON capacitor and so on imported components.



3. We adopt SMT technology to decrease failure rate and it is convenient to repair the machine and reduce the cost of repairing,we just need to change the bad pcb board.



4. We have successfully exported to Indonesia, Malaysia, and Thailand and so on foreign countries in all more than ten thousand of each model.We all get good feedback.



5. For large order,our engineer can come to your country Site Instruction.



6. We give customer 1% FREE SPARE PARTS (include pcbs with components and additional mosfet tube and components) to support repairment.



7. We provide a FREE ONE YEAR WARRANTY for all our items.



8. OEM brand.





Strong Welding Capacity:





Achievements:



Our competive :





* BUY WITH CONFIDENCE.

* QUALITY MACHINES MANUFACTURED BY ANDELI.

* FULL SERVICE AND PARTS BACK UP.

* 12 MONTHS WARRANTY.



The data in the above table is only for reference. Please subject to the nameplate on the device.





Why not try one sample first?Choosing our products,give yourself maximum profit. Inquires are typically answered within 24 hours.





More details are welcomed to contact us at any time , will be replied soon in 24 hours!
