AI-208 industrial temperature thermostat
ISO9001 certification and CE certified, achieving world class level of quality, anti-interference ability and safety
I. Technical Specification:
1. Input type : K,T, E, J, N, PT100
2. output type: Relay, SSR voltage output.
3. Accuracy : 0.3%FS±2°C
4. Resolution : 1℃ or 0.1 ℃
5. Control mode: On-off control or PID control
6. Alarm function: High Alarm, Lower limit alarm,Deviation High Alarm.
7. Power supply voltage rating: 100-240VAC, -15%, +10% / 50-60Hz or 24VDC
8. Ambient temperature: -10~+60°C, Humidity: 0~90RH%
___________________________________________________________________________
II. Front panel and Operation:
___________________________________________________________________________
III. Model Code:
The type of AI-208 temperature control is made up of 4 parts:
AI-208 A1 L L0
1 2 3 4
Part 1:
AI-208 Type PID economic temperature controller, accurancy 0.3%FS±2°C
Part 2: Dimension
Part 3:Output Type
L: Relay contact output module, capacity 2A/250VAC, normal open.
Part 4: Alarm
N: No alarm.
L0: 1 alarm
L3: 2 alarm
1) Factory with 25 years experience.
2) Quick delivery ( within 3~5 working days).
3) Retail/Wholesale/OEM/ODM available .
We expect to cooperate with machinery manufacturers,
better price for bulk order.
4)We provide after sales service and technical assistance as per the
customers requirement and needs.
1) A piece of heating controller ;
2) A paper of user manual;
3) One-year/ 3-year warranty card and Quality Approval card;
4) A lable of units;
5) A pair of installaton brackets;
6) Nice package carton box with Yudian logo.
1. How long will you give me the reply?
we will contact you as soon as possible.
2. Could I get samples of industrial temperature thermostat?
Yes,we have products in stock ,so you can get the samples quickly.
3. How about the quality of industrial temperature thermostat?
We have the certification of ISO,CE and ROSH,we could send the certification test of our company to you.
4. Could I visit your factory?
Of course,if you need we will help you to visit our factory.
5. If I have paid,when will you help me to produce?
We will start producing immediately after receiving the payment.
