Backhoe Loader With Cummins Engine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
Shenwa Machinery
Model Number:
SZ40-15E
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Brand Name
Shenwa Machinery
Model Number
SZ40-15E
Place of Origin
Shandong, China
Type
Backhoe Loader
Moving Type
Other, Wheel Loader, Wheel Excavator
Rated Load
6800kg
Specifications
1.Name: backhoe loader with cummins engine2.Rated power:74kw
3.Engine brand:Cummins
Excavator part | |
Max digging depth |
3000mm |
Max digging height |
5600mm |
Max digging radius |
5200mm |
Max dumping height |
4300mm |
Bucket capacity |
0.4m*3 |
Working efficiency |
30-60m*3/h |
Working times |
4-7times/min |
Max hauling force |
29kn |
Max swing angle of boom |
180 |
Loading part | |
Max dumping height |
2900mm |
Min rotary radius |
5000mm |
Max dumping distance |
950mm |
Rated loading mass |
1500kg |
Lifting time of movable arm |
3.5s |
Falling time of movable arm |
2.5s |
Summational time |
7.0s |
Max breakout force |
10.5kn |
Bucket capacity |
1m3 |
engine | |
model |
4108/Cummins
|
Rated power |
83kw/74kw |
Rated revolution |
2400r/min |
specification | |
Working pressure |
28Mpa |
Max flux |
63ml/r |
Total weight |
5500kg |
Gradeability |
25% |
Walking speed |
<=39km/h |
Distance between axles |
2700mm |
Overall dimension(L*W*H) |
7600*2005*2700mm |
