Specifications
1.Name:wheel backhoe loader for sale2.Engine: Cumminus
3.Rated Power:74kw
Overall Operating Weight |
7800KG |
Hub Reduction Type |
One-stage Hub Reduction |
Transportation Size |
|
Rated Axle Load |
7.5t |
L*W*H mm |
6239×2268×3760 |
Drive System |
|
Wheel Base |
2250mm |
Torque Converter |
|
Min. Ground Clearance |
300mm |
Model |
YJ280 |
Load Capacity of Bucket |
1.0m3 |
Type |
Single-stage, Single-phase Three-element |
Breakout Force |
38KN |
Peak Efficiency |
84.4% |
Load Lifting Capacity |
2500KG |
Inlet Pressure |
0.4Mpa—0.55 Mpa |
Dumping Height of Bucket |
2742mm |
Outer Pressure |
1.2Mpa—1.5 Mpa |
Dumping Distance of Bucket |
1062mm |
Cooling Type |
Oil Cold Pressure Circulation |
Max. Excavation Depth |
52mm |
Transmission |
|
Backhoe Bucket Capacity |
0.3 m3 |
Type |
Counter Shaft Power-shift |
Max. Excavation Depth |
4503mm |
Clutch Pilot Oil Pressure |
1373Kpa—1569 Kpa |
Rotary Angle of Bucket |
190o |
Gear Number |
Two Advance Gears, Two Reverse Gears |
Max. Traction Force |
39KN |
Max. Speed |
22Km/h |
Engine |
|
Tyre |
|
Model |
YTR4108G60-1 |
Specification |
16/70-20 |
Type |
Straight, Direct Injection, Four-stroke, Direct-spraying Combustion Chamber |
Air Pressure of Front Tyre |
0.22 Mpa |
Cylinder Number-Inner Diameter-Stroke |
4-108×120 |
Air Pressure of Rear Tyre |
0.22 Mpa |
Rated Power |
55KW |
Brake System |
|
Rated Rotational Speed |
2400r/min |
Service Brake |
Air-over-oil Caliper Disc Brake |
Min. Fuel Consumption |
≤216g/km.h |
External |
|
Max. Torque |
≥261.7N.M/1800r/min |
Self-regulation |
|
Displacement |
4.4L |
Self-balancing |
|
Steering System |
|
Parking/Emergency Brake |
Operating Force to Exert Brake |
Steering Gear Model |
BZZ5-250 |
Manual Operating Force to Relieve Brake |
|
Steering Angle |
±36 o |
Hydraulic System |
|
Min. Turning Radius |
5018mm |
Breakout Force of Bucket |
46.5KN |
System Pressure |
12Mpa |
Breakout Force of Bucket Rod |
31KN |
Drive Axle |
|
Lifting Time of Bucket |
5.4S |
Manufacturer |
Feicheng Axle Plant |
Fall Time of Bucket |
3.1S |
Main Drive Type |
Double-stage Reduction Type |
Dumping Time of Bucket |
2.0S |
