Garden Tools Repair Bandage/Oil & Gas Resistant Armor Wrap Tape for Pipe,Cable Protection

Emergency pipe repair bandage is a fast curing tape composed of a flexible fiberglass mesh impregnated with water activated polyurethane resin. It's applied to repair plastic, PVC, concrete, ceremic and all metal pipes carrying water, oil, steam and most gases and solvents; Also they can be used to repair & joint furniture or equipment such as furniture legs, large yard tools, handle tools, fishing rods, tent poles, etc. It's easy to use, the repaired items can be returned to service in 30 minutes.

• Catalyst: Water
• Resin Makeup: Polyurethane
• Heat Resistance: 150°C
• Pressure: 360 PSI (2,500KPA)
• Bonds: Copper pipe, PVC, polypipe, metal, fibreglass
• Set Time: 20 – 30 minutes, sets under water
• Chemical resistance: Most diluted chemicals and fuels



• Useable life:     2-3 minutes, depending on temperature of water and pipework
• Intial cure time:    5 minutes
• Full cure time:     30minutes
• Shore D hardness:   70
• Tensile strength:    30-35Mpa
• Tensile modulus:    7.5Gpa
• Maximum service temperature:   150°C
• Pressure resistance:    450psi (Min wrapping 12 layers around cracked/leaking area)

1.  Once the leaking area is identified, shut down relevant pipes or hoses immediately.

2.  Prepare the surface by cleaning and roughening the pipe.

3.  Put on enclosed latex gloves.

4.  Apply Steel Putty to the leak site and mould.

5.  Open foil pouch and immerse bandage in temperate fresh water for 10 seconds.

     The entire contents must be used once the package is opened.

6. Apply around the damaged area extending up to 50mm either side of the leak to ensure complete coverage.

    It is important that the bandage is applied.

7.  quickly as curing begins once it is taken out of the water.

8.  Whilst wrapping, pull each layer tightly by using your hand to mould and squeeze the layers together.

    Continue this action during and upon completion.

Packaging Details: Iindividual PE bag-10rolls/hard box-12rolls/corrugated ctn;

                              Individual Blister bag-10rolls/hard box-9rolls/corrugated ctn.

                                                                OEM service is available

• 13 years profesional manufacture of Armor Wrap, Fiberglass Pipe Repair Bandage , Orthopedic Fiberglass Casting Tape
• FDA CE Certfication
• OEM your size and backing
• Various Colors for Choose
• 7-15 Working Days for Delivery
• Free Samples Offered for Evaluation

Ansen Medical main products: Pipe Repair Bandage, Steel Putty, Gloves, Orthopedic Fiberglass Casting Tape. Our machine equipments are imported from Germany. We have a full range of automatic, microcomputer quality control throughout production lines and have passed the quality certification of CE and FDA.
