Production line band conveyor structure available to service machinery overseas
Basic speasification KISSTONE
Belt conveyor is the main transporting equipment widely used in industrial and mine enterprises. It is a continuous conveying equipment with conveyor belt to convey the materials through the transmission movement of the materials. It utilizes the internal friction and lateral pressure characteristic of the bulk materials and receives the puling force from drive rollers dragging them in its movement direction to increase their internal pressure. The internal friction ensures that the internal friction among material layers is bigger than the external friction of the belt. And the carry roller under the belt moves forward along with materials. When external force ratio satisfies certain conditions, material flow are ensured to be stable.
1.Simple structure, flexible layout
2.High working stability and reliability
3.Wide variety of transporting materials
4.Low cost, low energy consumption,high efficiency
5.Large transport volume
6.High safety
7.Convenient loading and unloading of materials
8.Wide application field
Product parameters:
Model |
Convey length |
Motor power |
Belt speed (M/S) |
Belt width (MM) |
Installation dip angle (°) |
Drive roller |
diameter |
Carry roller diameter(mm) |
Conveying capacity(t/h) |
TDZ500 |
L 12 |
4kw-4 |
1.6 |
500 |
15-18 |
320 |
500 |
89 |
40-80 |
12 L≤20 |
5.5kw-4 |
||||||||
20 L 30 |
7.5kw-4 |
||||||||
TDZ650 |
L≤10 |
4kw-4 |
1.6 |
600/650 |
15-18 |
320 |
500 |
89 |
60-120 |
10 L≤18 |
5.5kw-4 |
||||||||
18 L≤25 |
7.5kw-4 |
||||||||
25 L 35 |
11kw-4 |
||||||||
TDZ800 |
L≤10 |
5.5kw-4 |
1.6 |
800 |
15-18 |
480 |
630 |
89 |
100-300 |
10 L≤15 |
5.5kw-4 |
||||||||
15 L≤25 |
11kw-4 |
||||||||
25 L≤40 |
15kw-4 |
||||||||
40 L 60 |
18.5kw-4 |
||||||||
TDZ1000 |
L≤10 |
7.5kw-4 |
1.6 |
1000 |
15-18 |
630 |
800 |
108 |
200-400 |
10 L≤15 |
11kw-4 |
||||||||
15 L≤25 |
18.5kw-4 |
||||||||
25 L≤35 |
22kw-4 |
||||||||
35 L≤45 |
30kw-4 |
||||||||
45 L≤55 |
37kw-4 |
||||||||
TDZ1200 |
L≤10 |
15kw-4 |
1.6 |
1200 |
15-18 |
800 |
1000 |
108 |
400-850 |
10 L≤20 |
22kw-4 |
||||||||
40 L≤55 |
37kw-4 |
||||||||
TDZ1400 |
L≤10 |
22kw-4 |
1.6 |
1400 |
15-18 |
1000 |
1200 |
108 |
660-1200 |
10 L≤20 |
30kw-4 |
||||||||
40 L≤55 |
45kw-4 |
Product line:
Our factory KISSTONE
Company profile KISSTONE
Guangzhou Kisstone Import and Export Co.,Ltd. is specialized in R&D, manufacturing and sales of mine crushing machine, screening equipment and transportation equipment.
We have our independent production and casting base, modern metal cutting and processing equipment with advanced Solid Works 3D mechanical design system and simulation test system. Besides, we own a professional sales, technical and service team with more than 180 people of design, installation and on-site operation management, offering the complete solution and turnkey project for our customers.
Currently, our customers cover more than 20 provinces, cities and municipalities in China. Also, our products are exported to more than 60 countries in Europe, Latin America, Southeast Asia, Africa and so on, which are widely used in the global mining and construction industry.
Packaging & Shipping KISSTONE
F.A.Q KISSTONE
Q: How long is the warranty of your equipments? Does your company supply the spare parts?
A: The warranty period of Kisstone equipments is one year, so any questions, please contact us freely by 24 hours. And of course we will supply the spare parts for you for life-long time at lowest cost.
Q: Will you accept factory inspection?
A: Yes, of course. You are greatly welcome to visit our factory for you own inspection.
Q:Where is the manufacturer?
A: Zengcheng, Guangzhou,Guangdong Province of China.
