Home > Products > Desktop Gluing Machine > High Speed PCB Gluing Dispenser
High Speed PCB Gluing Dispenser
US$ 1 - 2
/ Set
1 Set(Min. Order)
- Guangzhou Shenzhen
- T/T Money Gram
You May Like
-
Glue Sealing Machine for LED Bulb Qpd-300
-
LED Bulb Lamp Gluing Machine Dispenser (QPD-300)
-
High Speed Desktop Glue Dispenser (SZD-200)
-
Silicone Desktop Gluing Sealing Machine (SZD-400)
-
High Precise Three Roating Stations Glue Dispensing Machine for Led Bulbs
-
Led Bulb Gluing Machine From Guangzhou Daheng
Product Details
| Condition | New | Application | Other, Machinery & Hardware | |
| Packaging Type | Cartons | Packaging Material | Wood | |
| Automatic Grade | Semi-Automatic | Driven Type | Pneumatic | |
| Voltage | AC220V or AC 380V | Place of Origin | Guangdong, China | |
| Brand Name | daheng | Model Number | SZD-300 | |
| Dimension(L*W*H) | 300*300*50mm | Weight | 40kgs | |
| Certification | CE, SGS | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
High Speed PCB Gluing Dispenser with good value,high speedEnglish operating version, manual, and training.
Easy operation
High Speed PCB Gluing Dispenser (SZD-300)
1. Features
1) Easy operation
Touch screen, English interface, store data, alarm system.
2) High accuracy of glue control:
All key parts imported, with unique control system, no affected by air pressure, avoiding uneven gluing, glue drawing, deckle edge, etc.
3)Quick program editing
In the gluing control system, we can store 99 programs according to different models of the products which have different dispensing track. It's very easy to select one of the programs when dispensing.
4) Simple adjustment for syringes:
Syringes can be adjusted in directions of up and down, left and right at a certain range, without change for the dispensing track.
5) Great generality, high speed:
1, 2, 4 needles dispensing head are available to improve the speed, widely used in various fluid, industry, and graphics (dot, line, curve, arc and round etc.)
2. High Speed PCB Gluing Dispenser Industrial Application
SMD, bulb lamp, COB binding, hand touch, TOP, dot matrix modules, circuit board, relay, cell phone and some other electric product with glue.
| Model & Type:SZD-200 High Speed PCB Gluing Dispenser | |
| Certificate | CE, SGS |
| Dimension | L610 X W500 X H600mm |
| N.W. | 40kg |
| XYZ Working Area | 300x300x50mm |
| Flow Speed | 0-66g/5s, or customized |
| Moving Speed | 0-300mm per second |
| Glue & Ratio | 1:1 to 20:1, Epoxy, Silicone, PU, UV |
| Repeatability | +/-0.02g |
| Accuracy | +/- 1% |
| Power | AC220V or AC 380V |
High Speed PCB Gluing Dispenser
High Speed PCB Gluing Dispenser
