High precision dispenser of glue /adhesive
Main Technical Data:
| Model No | PG-700 |
| Working Range X/Y/Z(mm) | 700x700x30mm |
| Mixing Ratio | 1:1~10:1(Adjustable) |
| Mixing Method | Static mixing/dynamic mixing |
| Metering Pump | Daheng Plunger Pump |
| Moving Track | Dot/Line/Curve/arc |
| Glue Pouring Speed | 5~66g/5s |
| Matching Accuracy | +/-1% |
| Volume of Container(L) | A30,B10 |
| Dimensions(mm) | 1500x1200x1500 |
| Weight(KG) | 260KG |
Features and Benefits:
1, A system of metering, mixing and potting.
2, Accurate metering and even mixing helps to avoid possible waste of glue,
3, Shot size and positioning keep consistent, fast.
4, Good universality makes PGB-700DR suitable for applications of LED, electric and others glue potting needed.
5, Easy to program and operate.
6, Tally function, non-standard mode, primer mode, level alert, filter mode, liquid display device, preventing backflow device and other functional device.
Application:
Industry: capacitor, power supply, transformer, ignition coil, reverse sensor, circuit board, electronic ballast, other electronic products and LED products where glue potting demanded.
LED Module Display Automatic Glue Pouring Machine
