We are professional leading factory in Guangzhou,China.
More than 10 years in manufacturing car paint spray booths.
We also sale automobile repair &maintenance equipments.
QX2000AB 2016 Good Quality Electric Heating Water Based Paint Spray Booth
Advantages:
1.We are direct factory,best sale modle number
2.One year warranty
3.100% inspection before deivery,100% trade assurance protection
4.Advanced microcomputer control system
5.Fast infrared lamps drying system(Diesel or gas drying can be customized)
6.Installation instruction service
7.Experienced in shipping.
The following specification is spray booth for car. If your painted items are furniture or others,please indicate it and ask details from Jessica.Thank you.!
| Inside Dimenions | 6900×3900×2650(mm)(L×W×H) |
| Outside Dimenions | 7000×5500×3300(mm)(L×W×H) |
| Entrance Door | Aluminum alloy binding framework(thickness: 1.8mm),1 set folding door size: 3000*2600(mm)(W*H) |
| Personal Door | 1 set side hung door:700*1700mm(W*H) |
| Wallboard | 50mm EPS(epispastics polystyrene )insulation material with S=0.426 two side steel panel |
| Lighting System | Lamp boxes are 45° fixed on upper two side,with 8 groups*3pcs=24pcs 16w energy saving LED lamp |
| Air Intake and Exhaust System | With 2pcs centrifugal air blowers,Total parameter:YOW5.6m.2*4kw.25000m3/h |
| Cabinet Setting | Intake air from upside,downside exhaust wind. |
| Air duct | Made of Galvanized plate(Thickness is 0.6mm),700*700*1000,2 pcs straight,1 pc elbow |
| Heating System |
30pcs infrared carbon fiber heating lamps,1000W/piece. The operating temperature:50℃-75℃.Max.temperature:80℃ |
| Filtration System | Filters |
| Roof | Galvanized steel panel |
| Basement | High performance antirust treatment grille galvanized and checkered plate(2 rows of checkered plate,3 rows of grilles). |
| Control System | Microcomputer touchable control system,Painting , Baking, Temperature Controller,Light Switch, Breakdown Indicator, Power Switch, Emergency Stop Switch, and Time Setting |
| Voltage Frequency | 380V 50HZ |
| Light Intensity | 1000luxes |
| Air Flow Speed | 0.25m/s |
| Total Power | 44KW |
Our project photo for reference.Photo are all rights reserved.
With 10 years professional production experiences in this area.
We had exported our spray booth baking oven for more than 50 countries with good feedback.
We accept custom made spray booth baking oven.
