Help CenterHigh Voltage Shunt Capacitor
Related Products
high voltage shunt capacitor1.sell on credit accepted
2. with CE,UL,ROHS,ISO9000 certification
3. minimum order accepted
4.excellent after-sell service
widely used in Power distribution station,Power system and so on for raising power factor of power system.
Technical performance 1. Equivalent adopting international standards IEC871-1. 2. Ambient air temperature range: -10°C to +40°C Altitude: not exceeding 1,000m. 3. Capacitors capacitance deviation may not exceed –5% ~ 18% of rated value. 4.Under power frequency rated voltage and when at 20°C, capacitors loss angle tangent value : no larger than 0.0005. 5. Capacitor is able to operate for a long period of time under highest value of operating voltage lower than 1.1-fold capacitor rated voltage. 6. Capacitor is allowed to operate over a long period time under less than 1.3 times capacitor rated current as a result of rise in voltage and
high harmonic stress.
| The Main Type and Data | |||||||||
| Order | Type | Rated Voltage(kV) | Rated output(kvar) | capacitance(uF) | Phases number | External dimensions(mm) | Weight (kg) | ||
| L | W | H(Case) | |||||||
| 1 | BFM11/ 3 -50-1W | 11/ | 50 | 3.946 | 1 | 380 | 135 | 460 | 18 |
| 2 | BFM11-50-1W | 11 | 50 | 1.315 | 1 | 380 | 135 | 460 | 18 |
| 3 | BFM12-50-1W | 12 | 50 | 1.105 | 1 | 380 | 135 | 460 | 18 |
| 4 | BFM11/ -100-1W | 11/ | 100 | 7.892 | 1 | 460 | 135 | 515 | 25 |
| 5 | BFM11-100-1W | 11 | 100 | 2.631 | 1 | 500 | 135 | 515 | 27 |
| 6 | BFM12-100-1W | 12 | 100 | 2.21 | 1 | 500 | 135 | 515 | 27 |
| 7 | BFM11/ -200-1W | 11/ | 200 | 15.784 | 1 | 460 | 170 | 650 | 44 |
| 8 | BFM11-200-1W | 11 | 200 | 5.261 | 1 | 500 | 170 | 650 | 48 |
| 9 | BFM12-200-1W | 12 | 200 | 4.421 | 1 | 500 | 170 | 650 | 48 |
| 10 | BFM22/ -200-1W | 22/ | 200 | 3.946 | 1 | 610 | 160 | 865 | 66 |
| 11 | BFM22.5-200-1W | 22.5 | 200 | 1.258 | 1 | 610 | 160 | 865 | 66 |
| 12 | BFM24-200-1W | 24 | 200 | 1.105 | 1 | 610 | 160 | 865 | 66 |
| 13 | BFM11/ -334-1W | 11/ | 334 | 26.359 | 1 | 717 | 170 | 690 | 74 |
| 14 | BFM11-334-1W | 11 | 334 | 8.786 | 1 | 717 | 170 | 690 | 74 |
| 15 | BFM12-334-1W | 12 | 334 | 7.383 | 1 | 717 | 170 | 690 | 74 |
| 16 | BFM19-334-1W | 19 | 334 | 2.945 | 1 | 745 | 190 | 865 | 91 |
| 17 | BFM20-334-1W | 20 | 334 | 2.658 | 1 | 745 | 190 | 865 | 91 |
| 18 | BFM22.5-334-1W | 22.5 | 334 | 2.1 | 1 | 745 | 190 | 865 | 91 |
| 19 | BFM24-334-1W | 24 | 334 | 1.864 | 1 | 745 | 190 | 865 | 91 |
| 20 | BFM11-100-3W | 11 | 100 | 2.631 | 3 | 640 | 135 | 570 | 42 |
| 21 | BFM11-200-3W | 11 | 200 | 5.261 | 3 | 640 | 135 | 685 | 53 |
| 22 | BFM11-300-3W | 11 | 300 | 7.892 | 3 | 730 | 170 | 685 | 75 |
