TUV MCS CEC Certificated Monocrystalline 240W Solar Panel

Name: TUV MCS CEC Certificated Monocrystalline 240W Solar Panel
Brand: OSDA
SKU: 132584601
Availability: InStock

US$ 0.62 - 0.66 MOQ: 1 Piece

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

OSDA

Model Number:

ODA240-48-M

Ningbo Osda Solar Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name OSDA

Model Number ODA240-48-M

Material Monocrystalline Silicon

Size 1580x1062x45mm

Number of Cells 96pcs(8x12)

Max. Power 240W

Specifications

import solar panels
we provide best quality product to our customers with competitive price and excellent quality

import solar panels import solar panels import solar panels

Specifications

Model Type	ODA265-48-M	ODA260-48-M	ODA255-48-M	ODA250-48-M	ODA245-48-M
PeakPower(Pmax)	265	260	255	250	245
Maximum Power Voltage(Vmp)	49.92	49.82	49.82	49.72	49.63
Maximum Power Current(Imp)	5.31	5.22	5.12	5.03	4.94
Open Circuit Voltage(Voc)	60.88	60.76	60.76	60.63	60.51
Short Circuit Current(Isc)	5.83	5.73	5.62	5.53	5.40
Module Efficiency (%)	15.8	15.5	15.2	14.9	14.6
Maximum System Voltage (V)	1000
Maximum Series Fuse Rating (A)	10
Power Tolerance	0~+3%
Pmax Temperature Coefficients (W/°C)	-0.435%
Voc Temperature Coefficients (V/°C)	-0.35%
Isc Temperature Coefficients (A/°C)	0.043%
NOCT Nominal Operating Cell Temperature (°C)	47±2
Operating and Storage Temperature (°C)	-40~+85
Standard Test Condition (STC)	1,000W/m²;AM 1.5;25°C

Mechanical characteristics & Packaging

Cell Type	Mono-crystalline 125x125mm
No. of Cells	96(8x12)
Dimensions	1580x1062x45mm
Weight	20.5kgs
Front Glass	3.2mm high transmission,low iron,tempered glass
Frame	Anodized Aluminium Alloy
Junction box	IP65 Rated
Output cables	TUV 1X4mm²,length 90cm
Quantity/pallet	20pcs/pallet
Loading Quantity	560pcs / 40ft
