Help CenterRoHS Proved TD130 USB Telescope Digital Camera Equipped With Astronomical Imaging Software of Future Win Joe
Related Products
-
Compact TD10 Digital Telescope Camera Equipped With Astronomical Imaging Software of Future Win JoeNegotiableMOQ: 50 Pieces -
0.35MP RoHS Proved TA350-P Video Telescope Eyepiece CameraNegotiableMOQ: 50 Pieces
-
0.35MP TA35-N High Sensitivity Video Telescope Eyepiece Camera With RoHS ProvedNegotiableMOQ: 50 Pieces
-
0.35MP Digital Telescope Camera Comes With Astronomical Imaging Software of Future Win JoeNegotiableMOQ: 50 Pieces
-
RoHS Proved TEM1300 USB Telescope Camera Equipped With Astronomical Imaging Software of Future Win JoeNegotiableMOQ: 50 Pieces
Specifications
1.3MP sensor, 1280*1024 live image8 languages software
32, 64 bit windows8
Compact design
Built in 31.75mm filter thread
♦Features:
1. Digital imaging module: Wider dynamic range 1.3MP imaging module;
2. Imaging software: astronomical imaging software of Future Win Joe.
3. Camera connection: 24.5mm and 31.75mm (1.25”) eyepiece adapter;
4. Camera house: compact and light-weight D-shaped shell.
♦Function:
1. To preview images on screen of PC and to shoot pictures or to record movies;
2. To adjust the gain, contrast, exposure time, frame rate and color saturation manually for better images;
3. To offers function of images inverted vertically and horizontally that renders the image in its natural
orientation on screen
♦Benefits:
1. Easy installation, convenient operation;
2. Adapts to any telescope – 31.75mm (1.25”), and 24.5mm (0.965”) eyepiece tubes;
3. 1.25” adapter is threaded for standard eyepiece filters
4. Compatibility with Win/MAC/Linux;
5. High resolution of 1280*1024 for preview, picture shoot and video recording
6. Real active resolution, no interpolation, no jaggies in picture.
7. Copyright software with 8 languages version
♦Quality control:
CE issued by SGS laboratory Verification No. SHEMO0808001971T01C
FC issued by SGS laboratory Verification No.SHEMO081100389IT01C
ROHS issued by POCE laboratory, Verification No.POCE13072325TCR
Copyright software of Future Win Joe V1.0 Registration Code:2009SR035346
ISO9001-2008 issued by kaixin certification co., Ltd Verification No. 06913Q12896R0S
♦OEM/ ODM:
Available for both hardware and software to be designed and made on clients' specification.
Including:
Logo package printing;
Optical system design;
PCB imaging module design;
Shell design ;
Software amendment.
♦Detial Specifications :
Capture Mode |
Picture and Video |
Active Resolution |
1280*1024 |
Pixel Size |
3.6µm*3.6µm |
Responsivity |
1.0V/ lux-sec |
Dynamic Range |
71dB |
S/N Ratio |
44dB |
Eyepiece Adapter Size |
31.75mm |
Power Supply |
USB Powered |
Device Weight |
0.27kg |
Device Size |
Φ74.00mm*56.9mm |
Cable length |
1.5m |
Spectral Range |
400-650nm(with IR-filter) |
Frame Rate |
17fps@1280*1024 |
Preview Model |
1280x1024,1280x800,1024x768,800x600, 640x480,352x288,320x240 |
Exposure |
ERS or Manual |
Power Consumption |
190mW |
White Balance |
Auto and manual |
PC Requirements |
CPU: Inter Core2 2.8GHz or Higher; Memory: 2GB or More;USB Port:USB2.0 High-speed Port |
Send Inquiry to This Supplier
