Specifications
1.3MP sensor no interpolatingDigital power 94X
8 languages software
32, 64 bit windows8,MAC
1280*1024 picture and video
♦ Features :
1. Digital imaging module: Wider dynamic range 1.3MP imaging module;
2. Imaging software: astronomical imaging software of Future Win Joe.
3. Camera connection: 24.5mm and 31.75mm (1.25”) eyepiece adapter;
4. Camera house: compact and light-weight round-shaped shell.
♦Appliction:
To update any type of optics telescope into digital telescope and to Increase the value of your telescope by adding powerful digital capability. No squinting with one eye, just be enjoyable and to share with others.
Connected with flective telescope Connected with refrective telescope
♦ Functions:
1. To preview images on screen of PC and to shoot pictures or to record movies;
2. To adjust the gain, contrast, exposure time, frame rate and color saturation manually for better images;
3. To offers function of images inverted vertically and horizontally that renders the image in its natural
orientation on screen
♦Benefits:
1. Easy installation, convenient operation;
2. Adapts to any telescope – 31.75mm (1.25”), and 24.5mm (0.965”) eyepiece tubes;
3. 1.25” adapter is threaded for standard eyepiece filters
4. Compatibility with Win/MAC/Linux;
5. High resolution of 1280*1024 for preview, picture shoot and video recording
6. Real active resolution, no interpolation, no jaggies in picture.
7. Copyright software with 8 languages version
♦Special design:
Compact in structure and light in weight, do not break the balance of standing of telescope when this usb
camera is added on ocular tube.
The software of Future Win Joe offers function of images inverted vertically and horizontally that renders the image in its natural orientation on screen, and no extra correcting lens is needed.
High quality PCB, sensor and processing chip offer low noise image.
♦Quality control:
CE issued by SGS laboratory Verification No. SHEMO0808001971T01C
FC issued by SGS laboratory Verification No.SHEMO081100389IT01C
ROHS issued by POCE laboratory, Verification No.POCE13072325TCR
Copyright software of Future Win Joe V1.0 Registration Code:2009SR035346
ISO9001-2008 issued by kaixin certification co., Ltd Verification No. 06913Q12896R0S
♦OEM/ODM:
Available for both hardware and software to be designed and made on clients' specification.
Including:
Logo package printing;
Optical system design;
PCB imaging module design;
Shell design ;
Software amendment.
♦Detail Specifications :
Capture Mode |
Picture and Video |
Max. Resolution |
1280*1024 |
Responsivity |
1.0V/ lux-sec |
Dynamic Range |
71dB |
Eyepiece Adapter Size |
24.50mm, 31.75mm |
S/N Ratio |
44dB |
Spectral Range |
400-650nm(with IR-filter) |
Preview Model |
1280x1024,1280x800,1024x768,800x600, 640x480,352x288,320x240 |
Exposure |
ERS or Manual |
Power Consumption |
190mW |
Frame Rate |
17fps@1280*1024 |
Power Supply |
USB Powered |
Device Weight |
0.27kg |
Device Size |
Φ74.00mm*56.9mm |
Cable length |
1.5m |
PC Requirements |
CPU: Inter Core2 2.8GHz or Higher; Memory: 2GB or More;USB Port:USB2.0 High-speed Port |
