500pc/h Capacity Egg Tray Maker

Egg tray maker

Egg Tray Machine (pulp moulding machine) consume used waste paper as raw

material and produce different kinds of paper tray according to your requirement,

such as egg tray/dishes ,egg carton/box,fruit tray,industrial package tray,seeding

tray ,win tray ,shoe support and small products packages ,etc. The different final

products are decided by your market choice.

We give the solution of the pulp moulding line as follows:

1. High automation, low labor required

2.Low production cost

3.Energy saving (by 20%-30% compared with other factory)

4.Water saving (complete water treatment system equipped)

5.Efficient Multilayer dryer, saving space (by 30% compared with traditional dryer)

6.Stable final product quality (same Model, same dimension,strong & good looking)

1. Paper Pulp Making System

2. Moulding System

Consist of 1pc of forming platen and 1 pc of transfering platen.

Platen size:1100x470mm,4sets of 30-cell egg tray molds can be mounted

on forming platen.

Moulding efficiency:5-6 cycles/min;

Equiped with vacuum auto draining system;auto cleaning system for the forming

mold and auto control cabinet.

Egg box Machine can produce various trays/cartons with different moulds as per

your specification or samp
Output Capacity:500--3000pcs per hour

3. Drying System

Drying Methods: Natural Sun Dried; Coal, gas, oil heating dried

Metal multilayer drying

Outline dimension:20080x2650x3600mm;

Single layer conveying chain;heated by section;multi burners;

Six layers drying line, energy saving and saving place

The temperature of each section can be adjusted independently;burners with French or Italian brand;
The energy for option: LPG,GAS,diesel oil,Equiped with auto control cabinet.

 Pre-sale service:
help you design the equipments layout. 2. take you see our factory. 3. answer all your question.
In-sale service: ensure the quality and delivery time.
After-sale service:
We supply videos and installation instruction to teach how to install the equipments.
