1000pcs/h Paper Recycling Egg Tray Machine
Egg Tray Machine (pulp moulding machine) consume used waste paper as raw
material and produce different kinds of paper tray according to your requirement,
such as egg tray/dishes ,egg carton/box,fruit tray,industrial package tray,seeding
tray ,win tray ,shoe support and small products packages ,etc. The different final
products are decided by your market choice.
We give the solution of the pulp moulding line as follows:
| Paper Pulp Making System |
Hydro-pulper,Vibra sieve machine,White water pump, pulp pump,Blender,Pulp making system |
| Tray Moulding System |
Rotary Molding Machine ,Forming Mold,Unloding Mold, Vacuum Pump,Air Compressor,Autospray,Vacuum Tank,Wate |
| Drying System |
Metal drying crust,Blower,Burner,Wet exhauster,Sheet Conveyer, Conveyer front driver,Conveyer rear driver,Packer machine |
1. High automation, low labor required
2.Low production cost
3.Energy saving (by 20%-30% compared with other factory)
4.Water saving (complete water treatment system equipped)
5.Efficient Multilayer dryer, saving space (by 30% compared with traditional dryer)
6.Stable final product quality (same Model, same dimension,strong & good looking)
| Model No. | STET--500 | STET--1000 | STET-1500 | STET--3500 |
| Output Capacity | 500 Pcs/h | 1000 Pcs/h | 1500 Pcs/h | 3500 Pcs/h |
| Power | 100kw | 200kw | 300kw | 500kw |
| Site needed | 50*18*4m | 50*20*4m | 50*25*4m | 50*30*4 |
| Control Method | PLC control | PLC control | PLC control | PLC control |
| Drying Method | Natural, Gas or Coal | Natural, Gas or Coal | Natural, Gas or Coal | Natural, Gas or Coal |
1. Paper Pulp Making System
| Item Name | Hydra pulper | Paper Refiner | Pulp pump | Agitator | Vacuum tank |
| Quantity | 1 | 1 | 3 | 2 | 1 |
| Power Need | 7.5kw | 7.5kw | 2.2kw, 2.2, 1.5kw | 2.2kw, 1.5kw | 0 |
2. Moulding System
Consist of 1pc of forming platen and 1 pc of transfering platen.
Platen size:1100x470mm,4sets of 30-cell egg tray molds can be mounted
on forming platen.
Moulding efficiency:5-6 cycles/min;
Equiped with vacuum auto draining system;auto cleaning system for the forming
mold and auto control cabinet.
Egg box Machine can produce various trays/cartons with different moulds as per
your specification or samp
Output Capacity:500--3000pcs per hour
3. Drying System
Drying Methods: Natural Sun Dried; Coal, gas, oil heating dried
Metal multilayer drying
Outline dimension:20080x2650x3600mm;
Single layer conveying chain;heated by section;multi burners;
Six layers drying line, energy saving and saving place
The temperature of each section can be adjusted independently;burners with French or Italian brand;
The energy for option: LPG,GAS,diesel oil,Equiped with auto control cabinet.
Pre-sale service:
help you design the equipments layout. 2. take you see our factory. 3. answer all your question.
In-sale service: ensure the quality and delivery time.
After-sale service:
We supply videos and installation instruction to teach how to install the equipments.
