Specifications
IP to ASI digital gateway1,Support inputs 1Gps data
2,transmit 12 routs IP stream into TS
IP to ASI digital gateway
1.1 Outline
NDS3506(RX)Gigabits IP gateway is an head-end interface equipment which is used for DVB and Ethernet. This machine can be used to send IP stream, turning the TS stream into IP Stream. As part of IP stream receiver to turn the IP stream to MPEG-2 TS stream. Completely it can transmit 12 routes IP stream into TS stream
1.2 Features
l Input/output TS is MPEG-2 transmission stream
l IP frame structure, complies ITU G. 752, ITU-T G.804 standard
l IP signal physical interface complies ITU-TG.703 standard
l To turn 12 routes IP stream into TS stream through 1000M network interface
l The maximum output rate is 715Mbps
1.3 Performance index
Interface |
Interface input number |
IP IN :12 Routes |
Input |
IP |
|
Interface output number |
DVB ASI: 12 Routes |
|
output |
DVB ASI |
|
Interface specification |
ASI |
DVB Standard |
Miscellaneous |
Dimension |
44mm×482mm×433mm |
Temperature |
0~45operating-20~80Storage |
|
Power |
220VAC±10%,50Hz,25W |
