Proskit MT-1820 3 5/6 Dual Display DMM w/USB Connector Digital Multimeter With usb interface
- 1000 Piece / Pieces per Month
- Shenzhen
- Credit Card PayPal
- Acrel AMC16Z-FAK48 Electric Module Multi Channel Current Detection Module For Data Center Precision Cabinet
- Acrel AMC16Z-FAK48 Electric Muti channel Monitoring Module Data Center Precision Cabinet
- Acrel AMC16Z-FAK48 Electric Muti Channel Monitoring Module Data Center Precision Cabinet
- 48 Circuit Monitoring Data Center Monitor Power Supply Management Server Multi Loop Energy Meter AMC16Z-FAK48
- Acrel AMC16Z-FAK48 Electric Muti Channel Monitoring Module Data Center Precision Cabinet
- Din Rail Ac Power Meter AMC16Z-FAK48 Multi-circuit Energy Meter One RS485 Communication 48 Branch Full Electric Parameter
Product Details
Place of Origin: | Taiwan | Brand Name: | Proskit | Model Number: | MT-1820 |
Measuring Current Range: | 600uA~10A | Measuring Voltage Range: | AC 6v~750v/DC 600mv~1000v | Measuring Resistance Range: | 600~60MΩ |
Measuring Capacitance Range: | 40nF~200μF | Operating Temperature: | -10 ℃~50 ℃ | Dimensions: | 192x95x48 |
Product Description
Specifications
LCD Voltmeter Ammeter Ohm AC/DC Tester Digital1.Digital multimeter with usb interface
2.Original Brand New
Welcome To Skiliwah Team
1.Why Choose Us?
→ 5 years Golden Supplier.Customers spread all over the world.High quality and best reputation expecially for wholesale business.With our professional QC team and development team,we are able to supply the best quality of the products to our customers.
→ More than ten of thousands items for your choice, Items in stock Help you to save your money and time.
→ Professional QC term to control the parts quality to make sure our products always Top quality. Do business with us ensure your money buy right goods.
→ Best sales and products group,24 hours online make sure you can find us whenever you need us.Save you time for relaxing with your family.
2.Products Description:
Proskit MT-1820 3 5/6 Dual Display DMM w/USB Connector Digital Multimeter With usb interface
3 5/6 digits 5999 counts.
0.5% best accuracy.
Auto/Manual both range.
USB connector for PC.
Dual display with analog bargraph.
Extra functions: duty cycle, relative reference, Max/Min hold, data hold, auto power off, low battery indication.
Counter | 5999 |
Digits | 3 5/6 |
Panel size | 70×50mm, 33mm high figure |
Backlight | Y |
Analog bargraph | Y |
Auto/Manual ranging | Both |
DC (V) | 600mV/6V/60V/600V ±(0.5%+4d) |
1000V ±(1.0%+6d) | |
*** | |
AC(V) | 6/60/600V ±(0.8%+10d) |
750V ±(1.0%+10d) | |
DC(A) | 600μA/6000μA ±(1.0%+10d) |
60/600mA ±(1.0%+10d) | |
6A/10A ±(1.2%+10d) | |
AC(A) | 600μA/6000μA ±(1.5%+10d) |
60/600mA ±(1.5%+10d) | |
6A/10A ±(2.0%+15d) | |
Resistance(Ω) | 600Ω ±(0.8%+5d) |
6/60/600K/6MΩ ±(0.8%+4d) | |
60MΩ ±(1.2%+10d) | |
*** | |
Frequency(Hz) | 100/1000Hz ±(0.5%+4d) |
10K/100KHz ±(0.5%+4d) | |
1M/20MHz ±(0.5%+4d) | |
Capacitance(μF) | 40nF±(5%+30d) |
400nF/4μF/40μF±(3.5%+8d) | |
200μF±(5.0%+10d) | |
Temperature(C) | (-20C~400C) ±1.0+50d |
(400C~1000C) ±1.5+15d | |
Temperature (F) | (0F~750F) ±(1.0+5d) |
(750F~1832F) ±(1.5+5d) | |
Continuity with beeper | Y |
Diode test | Y |
Transistor test | Y |
Display hold | Y |
USB/RS232 interface | USB |
Automatic power off | Y |
Low battery indication | Y |
EN61010-1 CAT IV | 600V/1000VDC/750VAC |
Bettery | 1.5V AAA×2 |
Size (D×W×H)mm | 185×91×49 |
Weight (g) | 390g |
Individual Packing | Color box |
4.Shipping and Handing
1.We will ship goods in 3 days after confirm the payment.
2.Shippment way we accept DHL,UPS,Fedex,EMS,HOONGKONG POST etc.
3.Buyers are responsible for any customs duties if applicable.
4.We will put legal effort to minimize any GST or V.A.T.or other import taxes.However,the selling price excludes any tax/duty if applicable.
5.More details contact
More information, just contact Cynthia, thank you !
Please add My Skype: Skiliwah
Trademanager: Skiliwah
We'll respond to all enquires within 24hrs.
We are professional supplier of Phone parts, Camera parts ( LCD screen display, lens unit, mainboard, flex cable,button, Gear, CCD, and IC).
We will offer our surprise and technology to you,because we are not just a supplier, manufacturer,but a friend of you.itis our pleasure to help our friends.
Thanks for your time !
