Specifications
nomex insulated wire1.MOQ:400kg
2.Delivery time;15-30days
3.Accept sample order
4. Send sample
High conductivity nomex insulated copper wire
1. nomex insulated wire products pictures details:
Main products: Enameled aluminum round wire, enameled aluminum flat wire ,paper covered aluminum wire,paper covered copper wire,3M paper covered aluminum wire, telephone paper covered aluminum wire,Dupont covered aluminum wire,single-layer glass fiber covered aluminum wire, single-layer glass fiber covered copper wire, double-layer glass fiber covered aluminum wire, double-layer glass fiber covered copper wire
2. nomex insulated wire Products Characteristics
1) Corrosion resistance
2) Radiation resistance
3) High dielectric strength
4) Low temperature resistance
5) Good mechanical properties
3. nomex insulated wire specifications :
P
|
Name
|
paper wrapped wire |
|
Feature |
level wrapping |
|
Material |
Bare copper wire or squeeze bare flat wire confirms the National standard, smooth surface, low resistance. |
|
Standards |
IEC,NEMA,GB
|
|
Application
|
major apply to oil-immersed transformer |
|
Specification
|
rectangular wire a:1—10mm;b:2.0—16mm |
|
Resistivity
|
0.017Ω.mm2/m |
|
Breakdown voltage
|
560V |
|
Appearance
|
Fastness wrapping, tightness, uniformity, without drape |
|
Packing
|
Wooden spool, apply for custom specification |
4.Test reports of nomex insulated wire
Name |
paper covered aluminum wire (copper) |
|||||
Type |
ZBL |
|||||
Diameter |
5.00×18.00mm |
|||||
Standard |
GB/T7673.3-2008 |
|||||
Test item |
Unit |
Technical Requirement |
Test Result |
Single conclusion |
||
Appearance |
|
Fastness wrapping, tightness, uniformity, without drape |
OK |
OK |
||
|
Conductor Diameter |
Broad side |
mm |
±0.05 |
5.02 |
OK |
|
Narrow side |
mm |
±0.10 |
18.01 |
OK |
||
|
Thickness of insulation film
|
mm |
0.405-0.45-0.50
|
0.44 |
OK |
||
Resistance |
Ω/m |
aluminum≤0.02785 |
0.02754 |
OK |
||
Elongation |
|
>17% |
40% |
OK |
||
Overlap lapping |
mm |
≥2 |
2.3 |
OK |
||
Winding bend |
|
According to both sides talks things over |
Without edge Wrapping |
OK |
||
Packing |
|
Meet the export standard |
OK |
OK |
||
Quality control result |
|
OK |
||||
5. Application pictures of nomex insulated wire as follows
oil immersed Transformer, Reactor, Generator and other electric device
6.Equipments are being used testing nomex insulated wire
7. Telephone Paper details and paper cutter machine
8. Importing nomex insulated wire from Huayuan , you will be enjoyed best service as follows:
1) Trail order is welcomed, you can test our quality before making large quantity, even though we are wholesales supplier
2) We issued test reports for every shipment.
3) You can enjoy discounting and priority to produce first after you become to be our regular client.
9.Our Company Advantage:
1) About 20 years nomex insulated wire manufacture experiences.
2) Been Audit by UL Company and BV Company
3) We have a big Quality Control Team and can guarantee the quality and time of delivery
4) Many trade companies place orders from us.
Application
Certifications
10.Why choose us:
1) Factory direct and shipment in time.
2) Telephone paper/3M paper/ Nomex (Dupont)
3) Customized sizes, logo and packing are accept
4) Accept sample order
5) Can send sample to test quality before our customer place order
6) Goods are sold with return guarantee the goods quality.
Xuchang Huayuan Electric Apparatus Co.Ltd factory pictures:
